Pistons
4 cyl piston set 16844 for Vauxhall - 1964/6 1057 cc OHV Viva, CR 8.5 to 1 (7.5 when thick gasket fitted). 1966 OHV Viva 90, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.295 | 75.565 | 37.6174 | 2.925 | 2.975 | 1.481 | ||
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Alfa Romeo - c.r. 9
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84 | 67.5 | 34.5 | 21 | 3.307087 | 2.65748 | 1.358268 | 0.826772 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
6 cyl piston set 2366 for Commer - 40h.p. G2, 6TK, Invador, Corinthian
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 83.34375 | 39.6875 | 19 | 3.149606 | 3 9/32 | 1 9/16 | 0.748031 |
1 cyl piston set 4238 for Wolseley - 12.08h.p. 1271cc Hornet, High Comp. C.R 6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 70.64375 | 39.6875 | 14.2875 | 2.244094 | 2 25/32 | 1 9/16 | 9/16 |
6 cyl piston set 4653 for Chrysler - 19.8h.p. CJX, CMX, CTX, CJ, P2 Richmond, Kew, Plymouth, Mortlake, Wimbledon
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 93.6625 | 50.8 | 18.653125 | 2 7/8 | 3 11/16 | 2 | 47/64 |
4 cyl piston set 5430 for Humber - 12h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 2.73622 | 0 | 0 | 0 | |||
4 cyl piston set 7164 for Coventry Climax - 10h.p. 1122cc SV & OHV Type I, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.7875 | 36.5125 | 19.05 | 3 1/4 | 3 1/16 | 1 7/16 | 3/4 |
4 cyl piston set 7382 for Commer - 20.9h.p. N2, N3, N4, PN3, Q2, Q3, Superpoise, 30, 40, 60cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 25 | 2.952756 | 3.661417 | 2.007874 | 0.984252 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
4 cyl piston set 7665 for Austin - 8h.p. 900cc Big Seven, New Eight C.R 6.8 to 1, 8h.p. WD 5/6cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
6 cyl piston set 7797 for Armstrong Siddeley - 14h.p. 1666cc Twelve Plus, Fourteen plus
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
6 cyl piston set 8064 for Mercedes - 85h.p. Super L5, Super L35, OM5, Hercules NK56 Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 105 | 162.5 | 78 | 35 | 4.133858 | 6.397638 | 3.070866 | 1.377953 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
4 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
6 cyl piston set 8765 for Standard - 16h.p. 16/6 2143 cc Sixteen Flying Sixteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77.390625 | 39.290625 | 19.05 | 2.57874 | 3 3/64 | 1 35/64 | 3/4 |
6 cyl piston set 8915 for Commer - 20.9h.p. 15, 20 25cwt, B20, NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
4 cyl piston set 9036 for Ford - V8 22h.p. 2227cc Utility, V8, 60h.p. Export, 74, 82A, 922A, 022A C.R.6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
4 cyl piston set 9466 for Hercules - IXK, C.I
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 77.7875 | 36.5125 | 19.05 | 3 1/8 | 3 1/16 | 1 7/16 | 3/4 |
4 cyl piston set 10268 for Mercury - 100h.p. V8, 2-3 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 81.75625 | 45.24375 | 19.05 | 3 3/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 10705 for Morris - 13.4h.p. 1476 cc SV Oxford 1 1/2 Litre, Series MO
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.5 | 76.2 | 41.275 | 19.05 | 2.893701 | 3 8.8817841970013E-16/2 | 1 5/8 | 3/4 |
4 cyl piston set 11527 for Humber - 16.25h.p. SV 2267 cc Hawk, MkIV, MkV, MkVI. 4 Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 93 | 51 | 24 | 3 3/16 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
4 cyl piston set 12682 for Hillman - 1390 cc OHV Minx, Mark VIII, Husky Series I and II, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 82.55 | 46.99 | 22.225 | 3 8.8817841970013E-16/2 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 13394 for Ford - 4457 cc OHV 272 Engine V8
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 86.51875 | 45.24375 | 23.1648 | 3 5/8 | 3 13/32 | 1 25/32 | 0.912 |
4 cyl piston set 14297 for Standard - 1021 cc Flying Eight, CR 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
4 cyl piston set 15581 for Morris - 848 cc OHV Mini-Minor, CR 9.3 to 1. Special for Racing
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9158 | 73.5838 | 42.7482 | 15.875 | 2.477 | 2.897 | 1.683 | 5/8 |
4 cyl piston set 16203 for Austin - 1098 cc OHV A40 MkII, 1100. CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
4 cyl piston set 16410 for Austin - 1798cc OHV 1800 CR 8.2 to 1, RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
1 cyl piston set 17122 for Ford - 1699 cc OHV Taunus 17M Series 21, V4, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 85.8 | 39.4 | 24 | 3.543307 | 3.377953 | 1.551181 | 0.944882 |
4 cyl piston set 17357 for Austin, Morris - 1798cc OHV 1800 CR 8.2 to 1, RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
4 cyl piston set 17491 for Opel - 1897 cc OHC Rekord L, Coupe, Caravan, 1.9S Manta, Ascona, Voyage, 1.9 litre. CR 9 to 1. Rekord Sprint 1900HL, GT1900 CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93 | 87 | 45 | 23 | 3.661417 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17747 for Hillman - 1496 cc OHV Minx 1500, Hunter De Luxe, CR 8.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.53908 | 82.55 | 46.99 | 23.8125 | 3.2102 | 3 1/4 | 1.85 | 15/16 |
1 cyl piston set 18395 for Jaguar - 4235 cc Jaguar OHC MkX, E Type 2+2, 420, 420 G, XJ6 4.2 litre, XJ 4.2, Series 3 fuel injection CR 8 to 1. Daimler OHC Sovereign 4.2 litre limousine, Srs 3 Fuel...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 93.2688 | 47.244 | 22.225 | 3 5/8 | 3.672 | 1.86 | 7/8 |
1 cyl piston set 18515 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
4 cyl piston set 18539 for Ford - 1599 cc OHV Cortina 1600, Cortina 1600 GT, Capri 1600, Capri 1600GT, 2737E Engine Overbored to give 1761 cc. CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.0011 | 83.82 | 44.1706 | 20.6375 | 3.3465 | 3.3 | 1.739 | 13/16 |
4 cyl piston set 18648 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 cwt Van, Low Comp. CR 8 to 1 uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18681 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18698 for Austin - 1748 cc OHC Maxi 1750. CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 63.6905 | 35.84194 | 20.6375 | 3 8.8817841970013E-16/2 | 2.5075 | 1.4111 | 13/16 |
4 cyl piston set 18756 for Ford - 1993 cc OHC Cortina 2000, Cortina 2000L/XL/GXL/GT/E, Escort RS2000, Low Comp CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.8 | 78.25 | 40.35 | 24 | 3.574803 | 3.080709 | 1.588583 | 0.944882 |
1 cyl piston set 18949 for Ford - 1599 cc OHV Cortina 1600, Escort Mexico, Capri 1600/1600GT, uprated 711M Engine, CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 83.82 | 44.1706 | 20.6375 | 3.187 | 3.3 | 1.739 | 13/16 |
4 cyl piston set 19113 for Bedford, Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC, CR 7.3/8.5 to 1. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 79.375 | 41.3766 | 25.4 | 3.374 | 3 1/8 | 1.629 | 1 |
1 cyl piston set 19178 for Triumph - 1998 cc OHV 2000 Mk II from engine 50001, GT6 Mk III from Engine 10001, CR 8.85 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 81.7118 | 45.8216 | 20.6375 | 2.9405 | 3.217 | 1.804 | 13/16 |
1 cyl piston set 19271 for Continental - F6226, Industrial F226, PF226 RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.1375 | 89.69375 | 50.8 | 21.828125 | 3 5/16 | 3 17/32 | 2 | 55/64 |
2 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
1 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19471 for Chrysler, Hillman - 1598 cc OHV Avenger 1600 GLS/TC. High Comp CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19568 for Opel - 1698 cc Rekord, Caravan, 1.7 litre CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 87 | 45 | 23 | 3.464567 | 3.425197 | 1.771654 | 0.905512 |
1 cyl piston set 19692 for Datsun - 1770 cc OHC 1800, 180B, L18 Engine, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 78 | 38.1 | 21 | 3.346457 | 3.070866 | 1 1/2 | 0.826772 |
4 cyl piston set 19734 for Chrysler (France)Simca - 1812 cc OHC 180, Europa 160 GT, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.7 | 87.1 | 49.06 | 24 | 3.452756 | 3.429134 | 1.931496 | 0.944882 |
1 cyl piston set 19829 for Honda - 89 cc OHC C90, CD90, CE90, S90
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 55 | 26.1 | 14 | 1.968504 | 2.165354 | 1.027559 | 0.551181 |
4 cyl piston set 19914 for Ford - 1599 cc OHV Escort 1600, Sport 1600,Ghia 1600, 751M Engine, High Comp CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20013 for Toyota - 1591 cc Corona Mk II, 1600 DX, 7R Engine. 1707 cc Corona Mk II, Van DX Mk II for LPG 6R Engine. 1858 cc Corona Mk II, Hard Top 1900GL, 8R-C, 8R Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 84.75 | 39.75 | 22 | 3.385827 | 3.336614 | 1.564961 | 0.866142 |
4 cyl piston set 20128 for Land Rover, Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre, Rover 80, CR 7 to 1, Optional 4 Ring design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20201 for Opel - 1196 cc Kadett, L/Coupe/Caravan L, Rallye Kadett, Manta, Ascona, 1.2S, Kadette City, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 76 | 38 | 20 | 3.110236 | 2.992126 | 1.496063 | 0.787402 |
4 cyl piston set 20209 for Volkswagen - 1588 cc 1600N Engine, 75/85 bhp CR 8.2 to 1. 79 bhp CR 8.2 to 1 for USA with K-Jetronic Fuel Injecton Golf S, LS, GL, Scirocco S, LS, GT, GL, Passat S, LS,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.5 | 73.7 | 41.8 | 22 | 3.129921 | 2.901575 | 1.645669 | 0.866142 |
4 cyl piston set 20295 for Chrysler - 928 cc OHC Sunbeam, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.98462 | 52.3113 | 26.9621 | 17.4625 | 2.7553 | 2.0595 | 1.0615 | 11/16 |
6 cyl piston set 20319 for Ford - 2792 cc 2.8 Litre, V6, Injection and Carburettor Types, Granada LS/GL/Ghia, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.01 | 74.53 | 40.13 | 24 | 3.661811 | 2.934252 | 1.579921 | 0.944882 |
4 cyl piston set 20396 for Austin - 998cc Austin/ Morris Mini MkII 1000 OHV, Mini Clubman 1000/MkII 1100 OHV, Riley Elf, Wolseley Hornet. All CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.7733 | 34.0868 | 15.86738 | 2.542 | 2.5895 | 1.342 | 0.6247 |
1 cyl piston set 20460 for Chrysler - 928 cc OHC Sunbeam Overbored to give 996 cc, CR 10 to 1. (Only supplied in 060 for special conversion kits)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72.53224 | 52.3113 | 26.9621 | 17.4625 | 2.8556 | 2.0595 | 1.0615 | 11/16 |
1 cyl piston set 20557 for Yamaha - 123 cc DT 125 Trail, DT125 E, DT125 F, CR 6.7 to 1, Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66.1 | 33.2 | 16 | 2.204724 | 2.602362 | 1.307087 | 0.629921 |
6 cyl piston set 20615 for Jaguar - 3781 cc, Mk IX 3.8, Mk X 3.8, XK150, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.99 | 105.385 | 41.885 | 22.23008 | 3.424803 | 4.149016 | 1.649016 | 0.8752 |
1 cyl piston set 20773 for Austin, Mini, Morris, Riley, Wolseley - 998 cc Austin: 1968/9 Mini Mk II 1000. 1980 Onwards Metro 1000. Mini: 1970 onwards Clubman 1000, Mk II. Morris: 1968/9 Mini Mk II...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.7733 | 34.0868 | 15.86738 | 2.542 | 2.5895 | 1.342 | 0.6247 |
1 cyl piston set 21046 for Toyota - 1077 cc Corolla 1100(KE 10/15/16), Corolla 1100 Van(KE 16V), CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 60 | 36.1 | 18 | 2.952756 | 2.362205 | 1.42126 | 0.708661 |
4 cyl piston set 21127 for Leyland - 1993 cc O Series Engine, OHC, Freight Rover Sherpa 2000, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 60.25 | 35.3 | 20.65528 | 3.3245 | 2.372047 | 1.389764 | 0.8132 |
4 cyl piston set 21211 for Ford - 1294 cc 1.3 litre Engine, OHC Sierra 1300. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 64.46 | 41.45 | 24.003 | 3.110236 | 2.537795 | 1.63189 | 0.945 |
4 cyl piston set 21486 for Mazda - 1490 cc E5 Engine 323 1500GT, CR 10 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 3.031496 | 0 | 0 | 0 | |||
4 cyl piston set 21960 for Toyota - 2366 cc 22R, Camry, Coaster, Celica, Cressida, MkII, HI-Lux, Corona
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92 | 92.5 | 39 | 22 | 3.622047 | 3.641732 | 1.535433 | 0.866142 |
1 cyl piston set 91513 for Perkins - 3 Cyl 2.36 litre P3, 144. 4 Cyl 3.15 Litre, PA, PB, P4, 4.192. 6 Cyl 4.73 Litre PF, PG, P6, 6.288. Diesel, with original ring equipment
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 107.7722 | 57.0484 | 31.75 | 3.501 | 4.243 | 2.246 | 1 1/4 |
1 cyl piston set 169405 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 121.7676 | 74.2696 | 36.5125 | 4 | 4.794 | 2.924 | 1 7/16 |
1 cyl piston set 350023 for Lister - HRA, HRW, Series, Diesel. Water cooled Diameter is 4 1/4, Air Cooled is 4.252
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 127 | 73.0885 | 39.6875 | 4 1/4 | 5 | 2.8775 | 1 9/16 |
1 cyl piston set 350041 for Lister - ST Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 103.1875 | 65.151 | 33.3375 | 3 3/4 | 4 1/16 | 2.565 | 1 5/16 |
4 cyl piston set 350164 for Opel - 2068 cc 2.1D Engine, Blitz 2.1D, Rekord 2.1D, L, Berlina, Caravan, CR 21/22/24 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 88.75 | 53.8 | 28 | 3.464567 | 3.494094 | 2.11811 | 1.102362 |
4 cyl piston set 350201 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
1 cyl piston set 350263 for Land Rover - 2 1/4 Litre Series II and III, Diesel. CR 23 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
1 cyl piston set 350303 for Ford - 4196 cc 256 Cu.in 4 cyl Turbocharged, Series 6Y, 7000, Series 7A, 7600, 7700, Dexta Tractor, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 129.2606 | 70.3834 | 41.275 | 4.4007 | 5.089 | 2.771 | 1 5/8 |
1 cyl piston set 350382 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600. Also BSD333H/BSD444 Engine, Direct injection 4610, 4610SU Tractors, 6610, 6710...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
1 cyl piston set 350392 for Leyland - 0.401 and 0.402 Engines, 6540 cc Bear, Chieftains, Clydesdales, Guy Big J4, Reiver, Super Comet, Super Clydesdale, Super Reiver, Super Reiver 20, Tractor...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.188 | 145.5928 | 82.1436 | 41.275 | 4.22 | 5.732 | 3.234 | 1 5/8 |
4 cyl piston set 350977 for Opel - 1700 cc X1.7DTL Engine, Astra OHC Turbocharged Intercooled, Diesel, CR 23 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 67 | 44.92 | 26 | 3.248031 | 2.637795 | 1.768504 | 1.023622 |
1 cyl piston set 428705 for Ford - 4 cyl, 3610 cc 4D Thames Trader, 1 1/2-5 ton, Major, Power Major, Super Major Tractor. 6 cyl 5416 cc 6D Thames Trader 4-7 Ton, 590E, 592E Engine, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 99.9998 | 118.11 | 70.993 | 34.925 | 3.937 | 4.65 | 2.795 | 1 3/8 |
4 cyl piston set 578404 for Mercedes - 1988 cc 180D, 190D, 190DC, 110D, 200D, L319D, O319D, OM621, Engine. Diesel CR 21 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 102 | 48.6 | 26 | 3.425197 | 4.015748 | 1.913386 | 1.023622 |
4 cyl piston set 665712 for Fiat - 1089 cc 1100/103, Engine type 103, CR 6.7 to 1. 1100R Engine Type 103H000, CR 8.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
4 cyl piston set 666074 for Seat - 1438 cc 1430, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 77.25 | 37.75 | 22 | 3.149606 | 3.041339 | 1.48622 | 0.866142 |
6 cyl piston set 666973 for Fiat - 652 cc 126A, 126BB Engine, 2 Cyl, Air cooled. CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 3.031496 | 0 | 0 | 0 | |||
4 cyl piston set 667509 for Alfa Romeo, Nissan - 1186 cc 301.00 Engine, Alfa Romeo Arna 1.2SI, Nissan Cherry 1.2, CR 9.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
4 cyl piston set 768110 for Simca - 1118 cc 1100, 1100L, 1100S, 350 Engine, CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
4 cyl piston set 032.12.08 for Peugeot - 1124 cc XW7 Engine, OHC 104Z/ZR/ZA/GL/GR, 205 GL/GR/XL/XR. CR 9.7/10.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 73.5 | 40.05 | 19.5 | 2.834646 | 2.893701 | 1.576772 | 0.767717 |
4 cyl piston set 12587 JP for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
4 cyl piston set 18645 JP for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
