Pistons
JP Pistons
Vauxhall 2.3 engine (7.3:1) compression only
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Mini 850
5 ring - dish top - pinch bolt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9158 | 69.0118 | 38.0492 | 15.875 | 2.477 | 2.717 | 1.498 | 5/8 |
Austin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 98.2599 | 56.9849 | 28.575 | 3 1/4 | 3.8685 | 2.2435 | 1 1/8 |
Bedford / Vauxhall
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 79.0448 | 45.593 | 19.05 | 3 1/8 | 3.112 | 1.795 | 3/4 |
Land Rover 90 / 110 1986 - 1990
2495cc Tdi Diesel 19J
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.424 | 86.3092 | 54.5846 | 30.1498 | 3.56 | 3.398 | 2.149 | 1.187 |
6 cyl piston set 1965 for Chevrolet - 26h.p. LQ, LR, LT, BB, NA, NB, NC, ND, CU, 1/2, 1 1/2 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.1375 | 93.6625 | 47.625 | 25.146 | 3 5/16 | 3 11/16 | 1 7/8 | 0.99 |
4 cyl piston set 2396 for Graham - 23.35 h.p 3670cc Standard 6, Special 6, Companion 6, 33.8h.p. Standard 8, Special 8Custom 8, Supercharged 75
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 94.45625 | 53.18125 | 20.6375 | 3 1/4 | 3 23/32 | 2 3/32 | 13/16 |
1 cyl piston set 4330 for Lister - 5 h.p. B Type (Petrol)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 114.3 | 114.3 | 50.8 | 25.4 | 4 1/2 | 4 1/2 | 2 | 1 |
6 cyl piston set 4653 for Chrysler - 19.8h.p. CJX, CMX, CTX, CJ, P2 Richmond, Kew, Plymouth, Mortlake, Wimbledon
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 93.6625 | 50.8 | 18.653125 | 2 7/8 | 3 11/16 | 2 | 47/64 |
1 cyl piston set 5246 for Morris - 24.8h.p. 3519cc SV, C, CD, CV Series 1 1/2 - 5 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100 | 107.95 | 57.15 | 26.9875 | 3.937008 | 4 1/4 | 2 1/4 | 1 1/16 |
6 cyl piston set 5461 for Wolseley - 18h.p. 2299cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.58125 | 43.65625 | 20.6375 | 2.73622 | 3 3/32 | 1 23/32 | 13/16 |
4 cyl piston set 7168 for Standard - 10h.p. in 12h.p. chassis, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.75 | 45.5 | 19.05 | 2 1/2 | 3.100394 | 1.791339 | 3/4 |
6 cyl piston set 7393 for Morris - 25h.p. Overseas C.R 5.75 to 1, C.I
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 99 | 55 | 22 | 3.228346 | 3.897638 | 2.165354 | 0.866142 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
4 cyl piston set 7665 for Austin - 8h.p. 900cc Big Seven, New Eight C.R 6.8 to 1, 8h.p. WD 5/6cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
4 cyl piston set 7684 for Ford - 30h.p. V8 Flat Top 15, 40, 60, 80cwt, Passenger 20 seater, Sussex and Surrey, Rigid Six, B, BB, 46, 50, 51, 67, 1/2 to 1 1/2 ton C.R. 6.12 to 1. Aluminium.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 7691 for Ford - 8h.p. Model Y, 5cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 59.53125 | 24.60625 | 14.2875 | 2.23 | 2 11/32 | 31/32 | 9/16 |
1 cyl piston set 7763 for Morris - 11.9h.p. 1550cc SV Twelve Four S11 1937 to 37, 11.9h.p. OHV Twelve Four, 'T' Series III 1938 to 41
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 80.5 | 42.5 | 18 | 2.73622 | 3.169291 | 1.673228 | 0.708661 |
4 cyl piston set 7771 for Standard - 9.h.p 1052cc, Little 9, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.325 | 69.85 | 34.925 | 15.875 | 2 3/8 | 2 3/4 | 1 3/8 | 5/8 |
4 cyl piston set 7798 for Ford - 22h.p. V8 (Export 60h.p.) 73, 82C, 922C, )22C, 92D, 02D, 82Y, 92Y, 02Y, 75, Thames 1/2 to 6 ton C.R 6.6 to 1. Aluminium verson of piston 9036
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
6 cyl piston set 7806 for Vauxhall - 14h.p. 1781cc Light Six ASX
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 7816 for Standard - 9h.p. 1131cc Flying Nine C.R.6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 73.025 | 38.1 | 15.875 | 2.362205 | 2 7/8 | 1 1/2 | 5/8 |
1 cyl piston set 7819 for Rover - 10.8h.p. 21389cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 40.084375 | 78.184375 | 15.875 | 2.61811 | 1 37/64 | 3 5/64 | 5/8 |
4 cyl piston set 8089 for Ford - V8 3.6litre, Pilot V8 {Export 85h.p.) 78, 81A, 91A, 01A, 11A
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
1 cyl piston set 8108 for Commer - 26.85h.p. Aluminium version of 7396 with ring below gudgeon pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 92.25 | 51 | 24 | 3.346457 | 3.63189 | 2.007874 | 0.944882 |
6 cyl piston set 8243 for Vauxhall - 14.6h.p. 1781cc fourteen Six from Engine No. DX 520001, Drilled con-rod type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
4 cyl piston set 8712 for Hillman - 14h.p. 14/6, 1944cc SV, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 24 | 2.952756 | 3.63189 | 2.007874 | 0.944882 |
6 cyl piston set 8765 for Standard - 16h.p. 16/6 2143 cc Sixteen Flying Sixteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77.390625 | 39.290625 | 19.05 | 2.57874 | 3 3/64 | 1 35/64 | 3/4 |
1 cyl piston set 8810 for Hercules - CB, JXE3, JXG, JXA2. Also Diamond
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 100.0125 | 55.5625 | 25.4 | 3 1/2 | 3 15/16 | 2 3/16 | 1 |
4 cyl piston set 8915 for Commer - 20.9h.p. 15, 20 25cwt, B20, NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
6 cyl piston set 8979 for Dodge - 28.35h.p. All 3 7/16" bore models after engine 42000. US Army T118-WF31. Types F G H J K Series B1 and B2, 64, 103, 105, 123, 125
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 95.25 | 50.8 | 21.828125 | 3 7/16 | 3 3/4 | 2 | 55/64 |
6 cyl piston set 9068 for Chevrolet - 100h.p. 235 motor
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4875 | 101.6 | 52.3875 | 21.971 | 3 9/16 | 4 | 2 1/16 | 0.865 |
6 cyl piston set 9493 for Essex - 16.9h.p. Terraplane
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.46875 | 80.9625 | 42.8625 | 19.05 | 2 21/32 | 3 3/16 | 1 11/16 | 3/4 |
4 cyl piston set 10268 for Mercury - 100h.p. V8, 2-3 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 81.75625 | 45.24375 | 19.05 | 3 3/16 | 3 7/32 | 1 25/32 | 3/4 |
1 cyl piston set 10715 for Leyland - 3400 cc OHV 344 Tractor, CR 17.5 to 1, 4 cyl. 5103 cc OHV, 5.1 Litre, Redline Laird, Redline Terrier, CR 16.5 to 1, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95 | 120.8024 | 70.2564 | 34.925 | 3.740157 | 4.756 | 2.766 | 1 3/8 |
4 cyl piston set 11527 JP for - 16.25h.p. SV 2267 cc Hawk, MkIV, MkV, MkVI. 4 Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 93 | 51 | 24 | 3 3/16 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
4 cyl piston set 12682 for Hillman - 1390 cc OHV Minx, Mark VIII, Husky Series I and II, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 82.55 | 46.99 | 22.225 | 3 8.8817841970013E-16/2 | 3 1/4 | 1.85 | 7/8 |
1 cyl piston set 13394 for Ford - 4457 cc OHV 272 Engine V8
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 86.51875 | 45.24375 | 23.1648 | 3 5/8 | 3 13/32 | 1 25/32 | 0.912 |
4 cyl piston set 15581 for Morris - 848 cc OHV Mini-Minor, CR 9.3 to 1. Special for Racing
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9158 | 73.5838 | 42.7482 | 15.875 | 2.477 | 2.897 | 1.683 | 5/8 |
4 cyl piston set 16204 for Austin - 1098 cc OHV A40 MkII, 1100 Low Comp CR 7.5 to 1/ A35 6 Cwt Van, 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
4 cyl piston set 16410 for Austin - 1798cc OHV 1800 CR 8.2 to 1, RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
6 cyl piston set 17194 for Rambler - 196 Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 90.4875 | 55.7784 | 21.828125 | 3 1/8 | 3 9/16 | 2.196 | 55/64 |
4 cyl piston set 17357 for Austin, Morris - 1798cc OHV 1800 CR 8.2 to 1, RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
4 cyl piston set 17491 for Opel - 1897 cc OHC Rekord L, Coupe, Caravan, 1.9S Manta, Ascona, Voyage, 1.9 litre. CR 9 to 1. Rekord Sprint 1900HL, GT1900 CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93 | 87 | 45 | 23 | 3.661417 | 3.425197 | 1.771654 | 0.905512 |
1 cyl piston set 17753 for Triumph - 2498 cc OHV TR5PI, TR6PI, 2.5PI, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 61.976 | 28.971875 | 20.6375 | 2.9405 | 2.44 | 1 9/64 | 13/16 |
4 cyl piston set 18400 for Ford - 997 cc OHV Anglia, Thames 5-7 Cwt, 105E Engine, Perfect 107E Engine, CR 8.9 to 1, Thames 5-7 Cwt 307E Engine CR 7.5 to 1. 1198 cc OHV Anglia Super, Cortina,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 77.216 | 38.9636 | 20.6375 | 3.187 | 3.04 | 1.534 | 13/16 |
4 cyl piston set 18545 for Ford - 1499 cc OHV Cortina Super, 116E Engine, Cortina GT, 122E Engine, Using 1599 cc Crossflow Cylinder Head CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 77.1398 | 38.89375 | 20.6375 | 3.187 | 3.037 | 1 17/32 | 13/16 |
4 cyl piston set 18681 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18762 for Hillman - 1592 cc OHV Minx 1600, Super Minx Low Comp CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.53908 | 82.55 | 46.99 | 23.8125 | 3.2102 | 3 1/4 | 1.85 | 15/16 |
1 cyl piston set 19114 for Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum 1800, Low Comp, CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 77.216 | 39.2176 | 25.4 | 3.374 | 3.04 | 1.544 | 1 |
4 cyl piston set 19275 for Austin - 1748 cc OHC Maxi 1750HL, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 63.6905 | 35.84194 | 20.6375 | 3 8.8817841970013E-16/2 | 2.5075 | 1.4111 | 13/16 |
1 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19568 for Opel - 1698 cc Rekord, Caravan, 1.7 litre CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 87 | 45 | 23 | 3.464567 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 19734 for Chrysler (France)Simca - 1812 cc OHC 180, Europa 160 GT, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.7 | 87.1 | 49.06 | 24 | 3.452756 | 3.429134 | 1.931496 | 0.944882 |
1 cyl piston set 19829 for Honda - 89 cc OHC C90, CD90, CE90, S90
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 55 | 26.1 | 14 | 1.968504 | 2.165354 | 1.027559 | 0.551181 |
4 cyl piston set 19914 for Ford - 1599 cc OHV Escort 1600, Sport 1600,Ghia 1600, 751M Engine, High Comp CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20013 for Toyota - 1591 cc Corona Mk II, 1600 DX, 7R Engine. 1707 cc Corona Mk II, Van DX Mk II for LPG 6R Engine. 1858 cc Corona Mk II, Hard Top 1900GL, 8R-C, 8R Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 84.75 | 39.75 | 22 | 3.385827 | 3.336614 | 1.564961 | 0.866142 |
4 cyl piston set 20128 for Land Rover, Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre, Rover 80, CR 7 to 1, Optional 4 Ring design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20201 for Opel - 1196 cc Kadett, L/Coupe/Caravan L, Rallye Kadett, Manta, Ascona, 1.2S, Kadette City, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 76 | 38 | 20 | 3.110236 | 2.992126 | 1.496063 | 0.787402 |
4 cyl piston set 20209 for Volkswagen - 1588 cc 1600N Engine, 75/85 bhp CR 8.2 to 1. 79 bhp CR 8.2 to 1 for USA with K-Jetronic Fuel Injecton Golf S, LS, GL, Scirocco S, LS, GT, GL, Passat S, LS,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.5 | 73.7 | 41.8 | 22 | 3.129921 | 2.901575 | 1.645669 | 0.866142 |
4 cyl piston set 20295 for Chrysler - 928 cc OHC Sunbeam, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.98462 | 52.3113 | 26.9621 | 17.4625 | 2.7553 | 2.0595 | 1.0615 | 11/16 |
6 cyl piston set 20319 for Ford - 2792 cc 2.8 Litre, V6, Injection and Carburettor Types, Granada LS/GL/Ghia, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.01 | 74.53 | 40.13 | 24 | 3.661811 | 2.934252 | 1.579921 | 0.944882 |
4 cyl piston set 20396 for Austin - 998cc Austin/ Morris Mini MkII 1000 OHV, Mini Clubman 1000/MkII 1100 OHV, Riley Elf, Wolseley Hornet. All CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.7733 | 34.0868 | 15.86738 | 2.542 | 2.5895 | 1.342 | 0.6247 |
1 cyl piston set 20460 for Chrysler - 928 cc OHC Sunbeam Overbored to give 996 cc, CR 10 to 1. (Only supplied in 060 for special conversion kits)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72.53224 | 52.3113 | 26.9621 | 17.4625 | 2.8556 | 2.0595 | 1.0615 | 11/16 |
1 cyl piston set 20557 for Yamaha - 123 cc DT 125 Trail, DT125 E, DT125 F, CR 6.7 to 1, Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66.1 | 33.2 | 16 | 2.204724 | 2.602362 | 1.307087 | 0.629921 |
6 cyl piston set 20615 for Jaguar - 3781 cc, Mk IX 3.8, Mk X 3.8, XK150, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.99 | 105.385 | 41.885 | 22.23008 | 3.424803 | 4.149016 | 1.649016 | 0.8752 |
1 cyl piston set 20773 for Austin, Mini, Morris, Riley, Wolseley - 998 cc Austin: 1968/9 Mini Mk II 1000. 1980 Onwards Metro 1000. Mini: 1970 onwards Clubman 1000, Mk II. Morris: 1968/9 Mini Mk II...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.7733 | 34.0868 | 15.86738 | 2.542 | 2.5895 | 1.342 | 0.6247 |
1 cyl piston set 21046 for Toyota - 1077 cc Corolla 1100(KE 10/15/16), Corolla 1100 Van(KE 16V), CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 60 | 36.1 | 18 | 2.952756 | 2.362205 | 1.42126 | 0.708661 |
4 cyl piston set 21127 for Leyland - 1993 cc O Series Engine, OHC, Freight Rover Sherpa 2000, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 60.25 | 35.3 | 20.65528 | 3.3245 | 2.372047 | 1.389764 | 0.8132 |
4 cyl piston set 21211 for Ford - 1294 cc 1.3 litre Engine, OHC Sierra 1300. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 64.46 | 41.45 | 24.003 | 3.110236 | 2.537795 | 1.63189 | 0.945 |
4 cyl piston set 21486 for Mazda - 1490 cc E5 Engine 323 1500GT, CR 10 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 3.031496 | 0 | 0 | 0 | |||
4 cyl piston set 21960 for Toyota - 2366 cc 22R, Camry, Coaster, Celica, Cressida, MkII, HI-Lux, Corona
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92 | 92.5 | 39 | 22 | 3.622047 | 3.641732 | 1.535433 | 0.866142 |
1 cyl piston set 91513 for Perkins - 3 Cyl 2.36 litre P3, 144. 4 Cyl 3.15 Litre, PA, PB, P4, 4.192. 6 Cyl 4.73 Litre PF, PG, P6, 6.288. Diesel, with original ring equipment
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 107.7722 | 57.0484 | 31.75 | 3.501 | 4.243 | 2.246 | 1 1/4 |
1 cyl piston set 169405 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 121.7676 | 74.2696 | 36.5125 | 4 | 4.794 | 2.924 | 1 7/16 |
1 cyl piston set 350023 for Lister - HRA, HRW, Series, Diesel. Water cooled Diameter is 4 1/4, Air Cooled is 4.252
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 127 | 73.0885 | 39.6875 | 4 1/4 | 5 | 2.8775 | 1 9/16 |
1 cyl piston set 350041 for Lister - ST Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 103.1875 | 65.151 | 33.3375 | 3 3/4 | 4 1/16 | 2.565 | 1 5/16 |
4 cyl piston set 350164 for Opel - 2068 cc 2.1D Engine, Blitz 2.1D, Rekord 2.1D, L, Berlina, Caravan, CR 21/22/24 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 88.75 | 53.8 | 28 | 3.464567 | 3.494094 | 2.11811 | 1.102362 |
4 cyl piston set 350201 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
1 cyl piston set 350263 for Land Rover - 2 1/4 Litre Series II and III, Diesel. CR 23 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
1 cyl piston set 350303 for Ford - 4196 cc 256 Cu.in 4 cyl Turbocharged, Series 6Y, 7000, Series 7A, 7600, 7700, Dexta Tractor, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 129.2606 | 70.3834 | 41.275 | 4.4007 | 5.089 | 2.771 | 1 5/8 |
1 cyl piston set 350382 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600. Also BSD333H/BSD444 Engine, Direct injection 4610, 4610SU Tractors, 6610, 6710...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
1 cyl piston set 350392 for Leyland - 0.401 and 0.402 Engines, 6540 cc Bear, Chieftains, Clydesdales, Guy Big J4, Reiver, Super Comet, Super Clydesdale, Super Reiver, Super Reiver 20, Tractor...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.188 | 145.5928 | 82.1436 | 41.275 | 4.22 | 5.732 | 3.234 | 1 5/8 |
4 cyl piston set 350977 for Opel - 1700 cc X1.7DTL Engine, Astra OHC Turbocharged Intercooled, Diesel, CR 23 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 67 | 44.92 | 26 | 3.248031 | 2.637795 | 1.768504 | 1.023622 |
1 cyl piston set 428705 for Ford - 4 cyl, 3610 cc 4D Thames Trader, 1 1/2-5 ton, Major, Power Major, Super Major Tractor. 6 cyl 5416 cc 6D Thames Trader 4-7 Ton, 590E, 592E Engine, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 99.9998 | 118.11 | 70.993 | 34.925 | 3.937 | 4.65 | 2.795 | 1 3/8 |
4 cyl piston set 578404 for Mercedes - 1988 cc 180D, 190D, 190DC, 110D, 200D, L319D, O319D, OM621, Engine. Diesel CR 21 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 102 | 48.6 | 26 | 3.425197 | 4.015748 | 1.913386 | 1.023622 |
4 cyl piston set 665712 for Fiat - 1089 cc 1100/103, Engine type 103, CR 6.7 to 1. 1100R Engine Type 103H000, CR 8.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
4 cyl piston set 665946 for Fiat - 1438 cc 124 Coupe 2nd Series, 124 Sport, 125 2nd Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 81.45 | 41.95 | 22 | 3.149606 | 3.206693 | 1.651575 | 0.866142 |
6 cyl piston set 666973 for Fiat - 652 cc 126A, 126BB Engine, 2 Cyl, Air cooled. CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 3.031496 | 0 | 0 | 0 | |||
4 cyl piston set 667509 for Alfa Romeo, Nissan - 1186 cc 301.00 Engine, Alfa Romeo Arna 1.2SI, Nissan Cherry 1.2, CR 9.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
4 cyl piston set 768110 for Simca - 1118 cc 1100, 1100L, 1100S, 350 Engine, CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
4 cyl piston set 032.12.08 for Peugeot - 1124 cc XW7 Engine, OHC 104Z/ZR/ZA/GL/GR, 205 GL/GR/XL/XR. CR 9.7/10.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 73.5 | 40.05 | 19.5 | 2.834646 | 2.893701 | 1.576772 | 0.767717 |
4 cyl piston set 12587 JP for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
4 cyl piston set 18645 JP for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
