Pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 3889 for Morris - 19.2h.p. R, TX, 2 ton, Economy model
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 44.45 | 95.25 | 22.225 | 3.464567 | 1 3/4 | 3 3/4 | 7/8 |
1 cyl piston set 5055 for Fiat - 17h.p. 2516cc 518, Ardita 2000, Type O
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 102 | 48 | 24 | 3.228346 | 4.015748 | 1.889764 | 0.944882 |
4 cyl piston set 7058 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
4 cyl piston set 8152 for Vauxhall - 12h.p. 1442cc Twelve Four, I, C.R.6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 93.6625 | 57.94375 | 15.875 | 2.73622 | 3 11/16 | 2 9/32 | 5/8 |
4 cyl piston set 8657 for Morris - LCS, LD, PW 15, 30cwt, 15.95h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 2 1/2 | 2 3/4 | 1 7/32 | ||
1 cyl piston set 8923 for Armstrong Siddeley - 17h.p. 2394cc OHV Sports
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.675 | 78.184375 | 40.084375 | 15.875 | 2 5/8 | 3 5/64 | 1 37/64 | 5/8 |
8 cyl piston set 9155 for Buick - 37.81h.p. 60, 89, 90, 8 cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 104.775 | 58.7375 | 22.225 | 3 7/16 | 4 1/8 | 2 5/16 | 7/8 |
1 cyl piston set 9534 for Armstrong Siddeley - 6/8h.p. Direct Injection, 4 1/4 Stroke, 1000 rpm, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 115.57 | 66.04 | 31.75 | 4 1/4 | 4.55 | 2.6 | 1 1/4 |
4 cyl piston set 10014 for Humber - 12h.p. 1669cc SV Twelve
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
1 cyl piston set 10306 for Villiers - 147 cc Mark 15, 15HS. 208 cc Mark 20, 20HS
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 61.9125 | 33.3375 | 15.5448 | 2.480315 | 2 7/16 | 1 5/16 | 0.612 |
2 cyl piston set 10895 for Wisconsin - TF, 2 Cyl. VF, V, 4 Cyl. Air Cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 85.725 | 38.1 | 19.05 | 3 1/4 | 3 3/8 | 1 1/2 | 3/4 |
6 cyl piston set 11546 for Jaguar - 3442 cc , OHC 3.5 litre Xk120 MkVII, XK140 MkVII, type M, MkVIII, XK150 3.4, 3.4 litres Standard and MkII, High Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.99196 | 103.4161 | 55.0672 | 22.225 | 3.2674 | 4.0715 | 2.168 | 7/8 |
4 cyl piston set 12016 for Ford - 3622 cc SV 3.6 litre, Pilot, V8, CR 6.15 to 1, H lex for 11276
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
6 cyl piston set 12756 for Austin - 23.44h.p. 2639.4cc O.H.V. A90 Westminster 2.6 Lit/ A95 Low Comp. CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 87.3125 | 47.625 | 22.225 | 3 1/8 | 3 7/16 | 1 7/8 | 7/8 |
6 cyl piston set 13530 for Vauxhall - 23.44h.p. 2262 cc OHV 2 1/4 Litre, Velox, Cresta. Offset G Pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 79.0448 | 45.593 | 19.05 | 3 1/8 | 3.112 | 1.795 | 3/4 |
4 cyl piston set 14022 for Volkswagen - 1192 cc OHV: 1200, 15 cwt. Van, Kombi, Microbus, RWD Air Cooled, Low Comp CR 6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 80 | 38 | 20 | 3.031496 | 3.149606 | 1.496063 | 0.787402 |
4 cyl piston set 14360 for Hillman - 1494 cc OHV, Minx 1 1/2 Litre Low Comp CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 82.55 | 46.99 | 22.225 | 3.110236 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 14978 for Fiat - 633 cc OHV 600, Multipla, RWD.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 63.25 | 40.75 | 18 | 2.362205 | 2.490157 | 1.604331 | 0.708661 |
4 cyl piston set 15636 for Ford - 105E Opened Out to Give 1098 cc, CR 9.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.0011 | 64.29375 | 38.89375 | 20.6375 | 3.3465 | 2 17/32 | 1 17/32 | 13/16 |
4 cyl piston set 16178 for Triumph - 1147 cc OHV Herald 1200, Herald 12/50, Spitfire, Courier 5 cwt. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
4 cyl piston set 16204 for Austin - 1098 cc OHV A40 MkII, 1100 Low Comp CR 7.5 to 1/ A35 6 Cwt Van, 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
4 cyl piston set 16300 for Opel - 1680 cc 4 Cyl, Olympia Rekord, 1.7 Litre, CR 7.25 to 1, Steel Strut Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 95 | 45 | 22 | 3.346457 | 3.740157 | 1.771654 | 0.866142 |
4 cyl piston set 16412 JP for Rover - 1998 cc 60, 2 Litre, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 93.2942 | 61.5442 | 3.062992 | 3.673 | 2.423 | ||
1 cyl piston set 16854 for Fiat - 2279 cc OHV 2300, 114 Engine, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 85.3 | 42.3 | 22 | 3.070866 | 3.358268 | 1.665354 | 0.866142 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7494 | 75.565 | 37.6174 | 20 | 3.061 | 2.975 | 1.481 | 0.787402 |
1 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17358 for MG - 1798 cc OHV MGB1800, MGBGT, CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
4 cyl piston set 17483 for Datsun - 1595 cc OHV Bluebird 1600, DR411, Fairlady 1600 SP311 CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.2 | 88 | 45 | 22 | 3.433071 | 3.464567 | 1.771654 | 0.866142 |
4 cyl piston set 17546 for Toyota - 1490 cc OHV Corona 1500, 2R Engine, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 78 | 39 | 20 | 3.070866 | 3.070866 | 1.535433 | 0.787402 |
4 cyl piston set 17569 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, Low Comp, CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 81.8388 | 43.8404 | 25.4 | 3.374016 | 3.222 | 1.726 | 1 |
4 cyl piston set 17753 for Triumph - 2498 cc OHV TR5PI, TR6PI, 2.5PI, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 61.976 | 28.971875 | 20.6375 | 2.9405 | 2.44 | 1 9/64 | 13/16 |
2 cyl piston set 18242 for Volvo - 4 Cyl, 1986 cc OHV 142, 142E, 144, 144E, 145, 142S, 144S, 145S, 144DL, 145DL, 144GL, 1800E, 1800S, 1800ES, B20A, B20F, Engines, CR 8.7 to 1. B20B Engine, CR 9.5...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46 | 22 | 3.499606 | 2.795276 | 1.811024 | 0.866142 |
4 cyl piston set 18400 for Ford - 997 cc OHV Anglia, Thames 5-7 Cwt, 105E Engine, Perfect 107E Engine, CR 8.9 to 1, Thames 5-7 Cwt 307E Engine CR 7.5 to 1. 1198 cc OHV Anglia Super, Cortina,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 77.216 | 38.9636 | 20.6375 | 3.187 | 3.04 | 1.534 | 13/16 |
4 cyl piston set 18515 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
1 cyl piston set 18598 for Vauxhall - 3294 cc OHV Velox, Cresta, Viscount, Ventora, Victor 3300, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 77.978 | 44.5008 | 22.0091 | 3 5/8 | 3.07 | 1.752 | 0.8665 |
1 cyl piston set 18679 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1, 2733E Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18682 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18742 for Triumph - 1709 cc OHC, CR 8.8 to 1 from Engine JBB7510
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.48726 | 64.5668 | 34.0868 | 22.225 | 3.2869 | 2.542 | 1.342 | 7/8 |
4 cyl piston set 18796 for Triumph - 1854 cc OHC Dolomite, Dolomite 1850HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.987 | 70 | 34.1 | 22.225 | 3.424685 | 2.755906 | 1.34252 | 7/8 |
4 cyl piston set 19064 for Land Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.4454 | 25.4 | 3.562 | 3.938 | 2.301 | 1 |
1 cyl piston set 19115 for Vauxhall - 1972 On, 2279 cc OHC VX Four Ninety, Victor 2300SL, Magnum 2300. 1972/3 Viva 2300 SL, Firenza 2300 Sports SL, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 97.536 | 77.0636 | 39.0652 | 25.4 | 3.84 | 3.034 | 1.538 | 1 |
6 cyl piston set 19188 for Rover - 2995 cc 3 litre, Mk I, II and III, CR 8.75 to 1. 2625 cc 100, 2.6 litre CR 7.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 98.0186 | 66.3702 | 22.225 | 3.062992 | 3.859 | 2.613 | 7/8 |
4 cyl piston set 19275 for Austin - 1748 cc OHC Maxi 1750HL, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 63.6905 | 35.84194 | 20.6375 | 3 8.8817841970013E-16/2 | 2.5075 | 1.4111 | 13/16 |
2 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 19301 for Saab - 1985 cc OHC, 99, EMS, 99 L ER4, 99 L CM4, CR 8.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 75 | 40.1 | 24 | 3.543307 | 2.952756 | 1.57874 | 0.944882 |
1 cyl piston set 19472 for Chrysler - 1598 cc OHV Avenger 1600 GLS/TC. Low Comp CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19572 for Volkswagen - 1679 cc 1700, 411, 021 Engine, Air Cooled, CR 7.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 80 | 42 | 23 | 3.543307 | 3.149606 | 1.653543 | 0.905512 |
2 cyl piston set 19717 for Volvo - 4 cyl 1986 cc OHV: 142 from Engine 393950, 144 from Engine 428000, 145 from Engine 21050, B20A, B20F Engines. CR 8.7 to 1. B20E Engine, CR 10.2 to 1. 6 Cyl, 6...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 71 | 46 | 24 | 3 1/2 | 2.795276 | 1.811024 | 0.944882 |
4 cyl piston set 19737 for Toyota - 1588 cc 2T, 2TB, 2TC, Engines, Carina, CR 8.5 to 1, Celica 1600 ST, CR 9.4 to 1. Corolla
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 90.75 | 45.1 | 22 | 3.346457 | 3.572835 | 1.775591 | 0.866142 |
1 cyl piston set 19885 for Jaguar - 4235 cc Jaguar OHC MkX, E Type GT, E type 2+2, 420, 420 G, XJ 6 4.2 Litre, XJ 4.2, CR 9 to 11
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 100.8634 | 52.5526 | 22.225 | 3 5/8 | 3.971 | 2.069 | 7/8 |
4 cyl piston set 19915 for Ford - 1599 cc OHV Transit 75/90/115, 751M Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20015 for Toyota - 1897 cc 3R and 3R-B Engines, Crown, Stout, RS30, RS31, RS40, RS46
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 91 | 41 | 24 | 3.464567 | 3.582677 | 1.614173 | 0.944882 |
1 cyl piston set 20128 for Land Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre, Rover 80, CR 7 to 1, Optional 4 Ring design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20202 for Opel - 1698 cc 1.7 litre Rekord, Caravan, CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 87 | 45.1 | 23 | 3.464567 | 3.425197 | 1.775591 | 0.905512 |
4 cyl piston set 20216 for Honda - 1600 cc EF Engine, OHC Accord, CR 8.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 57.5 | 27.6 | 17 | 2.913386 | 2.26378 | 1.086614 | 0.669291 |
6 cyl piston set 20296 for Rover, Triumph - 2350 cc OHC, 2.3 Litre, CR 9.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81 | 70 | 40.1 | 23.8125 | 3.188976 | 2.755906 | 1.57874 | 15/16 |
1 cyl piston set 20397 for Austin, Morris - 1098 cc Austin A40 MkII 1100 OHV/Allegro 1100 De Luxe, Morris 1100/Minor 1000 OHV. 'A' Series Engine CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.0517 | 30.3276 | 15.86738 | 2.542 | 2.2855 | 1.194 | 0.6247 |
4 cyl piston set 20510 for Audi - 1272 cc Audi 50LS/GLS. CR 8.2 to 1, Pyrostrut design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75.01 | 65.55 | 38.65 | 20 | 2.95315 | 2.580709 | 1.521654 | 0.787402 |
4 cyl piston set 20611 for Ford - 1600 cc OHV Fiesta USA Version
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 81.71688 | 42.11828 | 20.6375 | 3.1884 | 3.2172 | 1.6582 | 13/16 |
1 cyl piston set 20646 for Mercedes - 2778 cc M130, 920/921 Engine, 6 cyl, 250C, 280S/SE/SL, 300SEL, U110.404, CR 8.7/9/9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.5 | 81.2 | 48 | 25 | 3.405512 | 3.19685 | 1.889764 | 0.984252 |
4 cyl piston set 20841 for Lancia - 1298 cc 813.302, 818.303 Engines, 85/87/89/92h.p. Fulvia Coupe Rallye 1.3, Fulvia Sport 1.3, Zagato, Fulvia GTF, Fulvia Berlina, Fulvia Coupe 1.3 S, Monte...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 80.9 | 45.9 | 22 | 3.031496 | 3.185039 | 1.807087 | 0.866142 |
4 cyl piston set 21069 for Mitsubishi - 1410 cc G12B, 4G12 Engine, OHC Mirage 1400, GL/GLX/GLS, Lancer 1400 EL/GL/SL, Celeste 1400 SR/GL/GSL Coupe. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.5 | 58 | 28.9 | 18 | 3.011811 | 2.283465 | 1.137795 | 0.708661 |
1 cyl piston set 21135 for Suzuki - 123 cc 1 Cyl TS125 C, C2, ERN, ERT, ERZ
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66 | 32.5 | 14 | 2.204724 | 2.598425 | 1.279528 | 0.551181 |
1 cyl piston set 21250 for Austin, Morris - 1275 cc A+ series, Maestro 1.3/L/HL/HLE, Metro L/HL/HLE/HLS/S, Montego 1.3, CR 9.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.6247 | 57.98566 | 38.0492 | 20.6375 | 2.7805 | 2.2829 | 1.498 | 13/16 |
1 cyl piston set 21776 for Suzuki - 970 cc F10A Engine, OHC Jimny SJ410/Q/V, 4WD, 110S40FK, 1000SJ40VC CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 2.57874 | 0 | 0 | 0 | |||
4 cyl piston set 22009 for Ford - 1297 cc Escort 1300 Popular L, Combi Van, Orion 1300 L
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.96 | 65.1 | 38.69 | 20.62988 | 3.699213 | 2.562992 | 1.523228 | 0.8122 |
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 350024 for Ford - 4D 250 Cubic inches, D Series, 2701E Engine Vertical, 2706E Inclined 4 cylinder. 6D 360 cubic inches, D series 2704E Vertical, 2709 inclined 6cyl, Diesel. CR...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.26875 | 71.040625 | 34.925 | 4 1/8 | 4 21/32 | 2 51/64 | 1 3/8 |
1 cyl piston set 350047 for Petter - PJ Series, Diesel, CR 17.5 to 1. Air cooled 3.8175" bore, Water cooled is 3.814"
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 96.9645 | 106.0958 | 63.6016 | 30 | 3.8175 | 4.177 | 2.504 | 1.181102 |
1 cyl piston set 350175 for Mercedes - 10809 cc OM346 Engine, 180/210h.p., Direct Injection Diesel, CR 17.5 to 1. LKA/L)1418, 1518, 1618, 1619, 1620, 1918, 1920, 2020, 2220, 2620, 0317, LS332, L334
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 128 | 161.417 | 85.268 | 44 | 5.03937 | 6.355 | 3.357008 | 1.732283 |
1 cyl piston set 350208 for Mercedes, Daimler Benz - 1988 cc OM615.913/915/937 Engines, 200D, L206D, L306D. Diesel. CR 21 to 1, Steel Strut Design.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 87.42 | 52.9 | 26 | 3.425197 | 3.441732 | 2.082677 | 1.023622 |
1 cyl piston set 350268 for Petter - PJ MkII, PJW Ser, Air and Water cooled Multi Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 96.8756 | 105.9942 | 63.59906 | 30 | 3.814 | 4.173 | 2.5039 | 1.181102 |
4 cyl piston set 350305 for Bedford, Ford Europe - 1760 cc CF220/250 Van, Transit CR 22 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 80.01 | 50.63236 | 26.9875 | 3 1/8 | 3.15 | 1.9934 | 1 1/16 |
1 cyl piston set 350382 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600. Also BSD333H/BSD444 Engine, Direct injection 4610, 4610SU Tractors, 6610, 6710...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
1 cyl piston set 350417 for Gardner - 15.5 litre 6LYT Automotive Engine 15500 cc Direct Injection Turbocharged Diesel, CR 15 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 140 | 200.25 | 122.3 | 58 | 5.511811 | 7.883858 | 4.814961 | 2.283465 |
4 cyl piston set 350979 for Ford - 1753 cc 59h.p, Courier 1.8D Van, Escort 1.8D (35/55 Combi Van, 40/60/55/75 Van, GLX/Ghia/L/LX/L Business, Popular, Encore, Popular Plus, LD/GLD), Fiesta 1.8D...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 73.5 | 45.7 | 26 | 3.248031 | 2.893701 | 1.799213 | 1.023622 |
4 cyl piston set 479404 for Perkins - 1621 cc OHV 4.99, 1.62 Litre Diesel after Engine No 7034968, CR 20 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 79.9211 | 45.7835 | 23.8125 | 3 8.8817841970013E-16/2 | 3.1465 | 1.8025 | 15/16 |
1 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
4 cyl piston set 663395 for Fiat - 633 cc OHV 600, Multipla RPB
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 70 | 40.8 | 18 | 2.362205 | 2.755906 | 1.606299 | 0.708661 |
4 cyl piston set 665733 for Fiat - 1197 cc OHV 124 Berlina Familiar,CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 80.05 | 40.55 | 22 | 2.874016 | 3.151575 | 1.596457 | 0.866142 |
1 cyl piston set 665872 for Fiat - 125 Berlina, Engine type 125A CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 83.7 | 44.2 | 22 | 3.149606 | 3.295276 | 1.740157 | 0.866142 |
4 cyl piston set 666359 for Fiat - 594 cc OHV 126, De Ville Air Cooled, CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.5 | 79.5 | 40 | 20 | 2.893701 | 3.129921 | 1.574803 | 0.787402 |
4 cyl piston set 667432 for Fiat - 903 cc 100 GL Engine, 127 Special, L/C/CL, 900T Pulmino, Fiorino, Panda 45. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 61.25 | 30.75 | 20 | 2.559055 | 2.411417 | 1.21063 | 0.787402 |
1 cyl piston set 667894 for Alfa Romeo, Fiat, Fiat iveco, OM, Renault, Seat - 2445 cc 8140.61 Turbocharged Engine, Alfa Romeo 35 AR 8 Turbo Van. Fiat Ducato DS 2500. OM Grinta Van 30, 32, 35,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93 | 89.8 | 54.8 | 32 | 3.661417 | 3.535433 | 2.15748 | 1.259843 |
6 cyl piston set 900042 for Ruston Hornsby - YD, YDA MkI, YD MkII, Diesel. Water Cooled Bore is 4.377, Air Cooled is 4.3785
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.2139 | 142.9385 | 84.201 | 41.275 | 4.3785 | 5.6275 | 3.315 | 1 5/8 |
4 cyl piston set 10157JP for Austin - 10h.p. Ten Four, 1125cc. New manufacture by JP Pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
2 cyl piston set 13530 JP for Vauxhall - 6 Cyl 23.44h.p. 2262 cc OHV 2 1/4 Litre, Velox, Cresta. Offset G Pin. 4 Cyl 16.63h.p. 1507 cc OHV 1 1/2 litre, Wyvern, Victor
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 79.0448 | 45.593 | 19.05 | 3 1/8 | 3.112 | 1.795 | 3/4 |
