Pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
1 cyl piston set 4238 for Wolseley - 12.08h.p. 1271cc Hornet, High Comp. C.R 6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 70.64375 | 39.6875 | 14.2875 | 2.244094 | 2 25/32 | 1 9/16 | 9/16 |
4 cyl piston set 7164 for Coventry Climax - 10h.p. 1122cc SV & OHV Type I, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.7875 | 36.5125 | 19.05 | 3 1/4 | 3 1/16 | 1 7/16 | 3/4 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
4 cyl piston set 7788 for Triumph - 10h.p. 1097cc Gloria G10
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62 | 74.6125 | 39.6875 | 15.875 | 2.440945 | 2 15/16 | 1 9/16 | 5/8 |
6 cyl piston set 7797 for Armstrong Siddeley - 14h.p. 1666cc Twelve Plus, Fourteen plus
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
4 cyl piston set 7808 for Standard - 12h.p. 1608cc, C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.978125 | 39.290625 | 15.875 | 2.73622 | 3 7/64 | 1 35/64 | 5/8 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 7984 for Standard - 10h.p. 1267cc Flying Ten C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 19.05 | 2 1/2 | 2 7/8 | 1 1/2 | 3/4 |
6 cyl piston set 8064 for Mercedes - 85h.p. Super L5, Super L35, OM5, Hercules NK56 Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 105 | 162.5 | 78 | 35 | 4.133858 | 6.397638 | 3.070866 | 1.377953 |
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
4 cyl piston set 8535 for Ford - 8h.p. 933cc Anglia, rings above pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 65.2526 | 31.115 | 17.4625 | 2.23 | 2.569 | 1.225 | 11/16 |
4 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
4 cyl piston set 8735 for Lanchester - 14.06h.p. 1809 cc Fourteen, Roadrider De Luxe, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.468 | 80.16875 | 44.45 | 17.77 | 2.42 | 3 5/32 | 1 3/4 | 0.699606 |
6 cyl piston set 8765 for Standard - 16h.p. 16/6 2143 cc Sixteen Flying Sixteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77.390625 | 39.290625 | 19.05 | 2.57874 | 3 3/64 | 1 35/64 | 3/4 |
6 cyl piston set 8829 for Morris - Oxford S II, 2062cc, 16h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 80.5 | 42.5 | 18 | 2.57874 | 3.169291 | 1.673228 | 0.708661 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
6 cyl piston set 9012 for Austin - 28h.p. 4016cc C.R. 6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.36 | 103.1875 | 58.7375 | 22.225 | 3.4 | 4 1/16 | 2 5/16 | 7/8 |
4 cyl piston set 9036 for Ford - V8 22h.p. 2227cc Utility, V8, 60h.p. Export, 74, 82A, 922A, 022A C.R.6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
6 cyl piston set 9301 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Cast Iron piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9462 for Armstrong Siddeley - 16h.p.1991cc 2 Litre, Lancaster, York, Hurricane, Typhoon
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 76.5 | 40 | 15.875 | 2.559055 | 3.011811 | 1.574803 | 5/8 |
1 cyl piston set 9749 for Douglas - 630cc SV Industrial Air Cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 80.9625 | 47.625 | 22.225 | 3 1/2 | 3 3/16 | 1 7/8 | 7/8 |
4 cyl piston set 10165 for Ford - 10 h.p. 1172cc SV Prefect, Export Anglia, 10cwt. Heplex version of 8743
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
4 cyl piston set 10268 for Mercury - 100h.p. V8, 2-3 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 81.75625 | 45.24375 | 19.05 | 3 3/16 | 3 7/32 | 1 25/32 | 3/4 |
1 cyl piston set 10520 for Lanchester - 10h.p. 1203 cc Car 20051 Upwards, 1287 cc OHV Ten LD10, CR 7.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 17.77 | 2 1/2 | 2 7/8 | 1 1/2 | 0.699606 |
1 cyl piston set 10648 for Austin - 28.8 h.p. 3993 cc O.H.V. 4 litre Loadstar, 2-5 ton, 6 Cyl. Austin Champ 18.9HP, 2660 cc 4 Cyl.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
6 cyl piston set 11248 for Hillman - 2810 cc 20/70, 3181 cc Hawk, 80
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11521 for Ferguson - 2088 cc OHV TVO Fuel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 86.36 | 49.784 | 22.225 | 3.346457 | 3.4 | 1.96 | 7/8 |
4 cyl piston set 11613 for Morris - 11.9h.p. 1550cc SV Twelve Four S11 1936 to 37, 11.9h.p. OHV Twelve Four, 'T' Series III 1938 to 41
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 80.5 | 42.5 | 18 | 2.73622 | 3.169291 | 1.673228 | 0.708661 |
4 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12380 for Standard - 803 cc OHV Eight, CR 7.25 to 1, Gold Star Power Plus, CR 8.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 66.1 | 38.1 | 15.875 | 2.283465 | 2.602362 | 1 1/2 | 5/8 |
1 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
4 cyl piston set 12587 for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
4 cyl piston set 12682 for Hillman - 1390 cc OHV Minx, Mark VIII, Husky Series I and II, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 82.55 | 46.99 | 22.225 | 3 8.8817841970013E-16/2 | 3 1/4 | 1.85 | 7/8 |
1 cyl piston set 13384 for JAP - 412 cc 5, 5B, 1 Cyl. 824 cc 55, 55C, 55CB, 2 Cyl. Air Cooled Industrial, Stationary
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.9846 | 76.8858 | 38.7858 | 20.6375 | 3.149 | 3.027 | 1.527 | 13/16 |
1 cyl piston set 13833 for Citroen - 425 cc OHV 2 CV, Bijou, FWD.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66 | 81.5 | 49.5 | 20 | 2.598425 | 3.208661 | 1.948819 | 0.787402 |
4 cyl piston set 14289 for Austin - 948 cc OHV A35/A40 Healey Sprite, High Comp CR 9.35 to 1. Healey Sprite MkII CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
6 cyl piston set 14816 for Austin - 2912 cc OHV A99 Westminster/A110 2.9 litre/ 3 litre Princess. CR 8.3 to 1 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
1 cyl piston set 15537 for Opel - 1488 cc Rekord 1.5 litre RBP Design for 15370
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 95 | 45 | 22 | 3.149606 | 3.740157 | 1.771654 | 0.866142 |
4 cyl piston set 16156 for Simca - 1290 cc OHV Aronde 1300, Flash Engine, 3 bearing crankshaft
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 86 | 48 | 22 | 2.913386 | 3.385827 | 1.889764 | 0.866142 |
4 cyl piston set 16203 for Austin - 1098 cc OHV A40 MkII, 1100. CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
4 cyl piston set 16224 for Austin - 1622cc OHV J2/J4, 10/18 Cwt. Omnivan/Omnitruck/Omnicoach. CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16376 for Vauxhall - 1964/6 1057 cc OHV Viva, CR 8.5 to 1 (7.5 when thick gasket fitted). 1966 OHV Viva 90, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.295 | 75.565 | 37.6174 | 20 | 2.925 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 16844 for Vauxhall - 1964/6 1057 cc OHV Viva, CR 8.5 to 1 (7.5 when thick gasket fitted). 1966 OHV Viva 90, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.295 | 75.565 | 37.6174 | 20 | 2.925 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 17122 for Ford - 1699 cc OHV Taunus 17M Series 21, V4, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 85.8 | 39.4 | 24 | 3.543307 | 3.377953 | 1.551181 | 0.944882 |
2 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17310 for Rover - 1980 cc OHC 2000TC, P6 Engine, CR 10 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 88.2396 | 56.5912 | 25.4 | 3 3/8 | 3.474 | 2.228 | 1 |
4 cyl piston set 17482 for Datsun - 4 cyl 988 cc OHV 1000. CR 8 to 1. 1189 cc OHV Bluebird 1200, El Engine, 1299 cc OHV Bluebird 1300, P411, J Engine, CR 8.2 to 1. 6 cyl 1973 cc OHV Cedric De...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.5 | 17.4498 | 2.874016 | 2.65748 | 1.279528 | 0.687 |
2 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17568 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 83.312 | 45.3136 | 25.4 | 3.374016 | 3.28 | 1.784 | 1 |
4 cyl piston set 17747 for Hillman - 1496 cc OHV Minx 1500, Hunter De Luxe, CR 8.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.53908 | 82.55 | 46.99 | 23.8125 | 3.2102 | 3 1/4 | 1.85 | 15/16 |
4 cyl piston set 18111 JP for Hillman - 876 cc OHC Imp, Super Imp, Husky C.R 10 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.98564 | 52.1843 | 26.797 | 15.875 | 2.6766 | 2.0545 | 1.055 | 5/8 |
4 cyl piston set 18393 for Jaguar - 3781 cc OHC Mk IX, 3.8 Lit, XK150 3.8, Mk X, S type, CR 8 TO 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.99 | 100.8634 | 52.5526 | 22.225 | 3.424803 | 3.971 | 2.069 | 7/8 |
1 cyl piston set 18515 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
4 cyl piston set 18539 for Ford - 1599 cc OHV Cortina 1600, Cortina 1600 GT, Capri 1600, Capri 1600GT, 2737E Engine Overbored to give 1761 cc. CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.0011 | 83.82 | 44.1706 | 20.6375 | 3.3465 | 3.3 | 1.739 | 13/16 |
4 cyl piston set 18648 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 cwt Van, Low Comp. CR 8 to 1 uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18681 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18698 for Austin - 1748 cc OHC Maxi 1750. CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 63.6905 | 35.84194 | 20.6375 | 3 8.8817841970013E-16/2 | 2.5075 | 1.4111 | 13/16 |
4 cyl piston set 18756 for Ford - 1993 cc OHC Cortina 2000, Cortina 2000L/XL/GXL/GT/E, Escort RS2000, Low Comp CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.8 | 78.25 | 40.35 | 24 | 3.574803 | 3.080709 | 1.588583 | 0.944882 |
1 cyl piston set 18949 for Ford - 1599 cc OHV Cortina 1600, Escort Mexico, Capri 1600/1600GT, uprated 711M Engine, CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 83.82 | 44.1706 | 20.6375 | 3.187 | 3.3 | 1.739 | 13/16 |
4 cyl piston set 19113 for Bedford, Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC, CR 7.3/8.5 to 1. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 79.375 | 41.3766 | 25.4 | 3.374 | 3 1/8 | 1.629 | 1 |
1 cyl piston set 19160 for Leyland - 2227 cc OHC 2200 E series/2200HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 74.7776 | 43.1292 | 20.6375 | 3 8.8817841970013E-16/2 | 2.944 | 1.698 | 13/16 |
1 cyl piston set 19271 for Continental - F6226, Industrial F226, PF226 RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.1375 | 89.69375 | 50.8 | 21.828125 | 3 5/16 | 3 17/32 | 2 | 55/64 |
4 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
2 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
1 cyl piston set 19471 for Chrysler, Hillman - 1598 cc OHV Avenger 1600 GLS/TC. High Comp CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19567 for Mercedes - 2277 cc 230/4 CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.75 | 82 | 51.8 | 26 | 3.690945 | 3.228346 | 2.03937 | 1.023622 |
4 cyl piston set 19691 for Datsun - 1428 cc OHC Violet 140J, Sunny 140, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38 | 21 | 3.267717 | 3.070866 | 1.496063 | 0.826772 |
4 cyl piston set 19734 for Chrysler (France)Simca - 1812 cc OHC 180, Europa 160 GT, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.7 | 87.1 | 49.06 | 24 | 3.452756 | 3.429134 | 1.931496 | 0.944882 |
4 cyl piston set 19828 for Saab - 1985 cc Injection Engines B20, BT20, B120, OHC, 2 Litre, 99L, 99 EMS, CR 9.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 75 | 40.1 | 24 | 3.543307 | 2.952756 | 1.57874 | 0.944882 |
1 cyl piston set 19914 for Ford - 1599 cc OHV Escort 1600, Sport 1600, Ghia 1600, 751M Engine, High Comp CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20009 for Datsun, Nissan - 1296 cc Bluebird 1300 for L.P.G. L13 Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38 | 21 | 3.267717 | 3.070866 | 1.496063 | 0.826772 |
1 cyl piston set 20188 for Volvo - 2127 cc B21A Engine, 242 DL, 244 DL, 245 DL, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92 | 71 | 46.1 | 24 | 3.622047 | 2.795276 | 1.814961 | 0.944882 |
1 cyl piston set 20317 for Ford - 2551 cc 2.6 litre V6, 26M, 2600 S, RS2600, Capri 2600 RS/ GT, Granada L, GL, GXL, Ghia, S, GLS and Turnier, CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 74.78 | 40.38 | 24 | 3.543307 | 2.944094 | 1.589764 | 0.944882 |
4 cyl piston set 20431 for Chrysler - 1294 cc OHV Alpine GL/Horizon GLS, 1442 cc OHV Alpine S/GLS. CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.692 | 64.5 | 37.6 | 22 | 3.01937 | 2.53937 | 1.480315 | 0.866142 |
2 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
1 cyl piston set 20979 for Suzuki - 100 cc GP100C/UC/N/UN, GP100D
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 60 | 31 | 14 | 1.968504 | 2.362205 | 1.220472 | 0.551181 |
4 cyl piston set 21207 for Nissan - 1598 cc CA16 Engine, Stanza 1600, Violet 1600, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 66.25 | 31.3 | 20 | 3.070866 | 2.608268 | 1.232283 | 0.787402 |
4 cyl piston set 21946 for Nissan - 1998 cc L20/A/P/S Engine. 1978 Bluebird. 81-83; Cedric CDX Sedan. 70-77; Fairlady. 66 On; Gloria. 72 On; Laurel. 81-84; Laurel Sedan CDX, GL, SGLHardtop GL. 68...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 75 | 40 | 20 | 3.070866 | 2.952756 | 1.574803 | 0.787402 |
6 cyl piston set 169405 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 121.7676 | 74.2696 | 36.5125 | 4 | 4.794 | 2.924 | 1 7/16 |
1 cyl piston set 350030 for Perkins - V8.510 From Engine 510U2000, 8.36 litre, Direct Injection Diesel CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 122.174 | 77.7875 | 41.275 | 4 1/4 | 4.81 | 3 1/16 | 1 5/8 |
1 cyl piston set 350199 for Ford - 3/4 cyl 175/256 cubic inches, Series 6Y, 3000, 5000, Super Major Tractor/Dexta, Series 7A, 3600, 333, 5600. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 129.0066 | 70.1802 | 38.1 | 4.2007 | 5.079 | 2.763 | 1 1/2 |
1 cyl piston set 350303 for Ford - 4196 cc 256 Cu.in 4 cyl Turbocharged, Series 6Y, 7000, Series 7A, 7600, 7700, Dexta Tractor, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 129.2606 | 70.3834 | 41.275 | 4.4007 | 5.089 | 2.771 | 1 5/8 |
4 cyl piston set 350387 for Nissan - SD20 Engines, 1991 cc, Cedric, Homer, Junior Wagon, KRSE20, Laurel 200D, Q140, VRE20, CR 20 to 1, and SD22 Engines 2164 cc, Caball, Cabstar, Caravan, Cedric,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 96 | 48.057 | 26 | 3.267717 | 3.779528 | 1.892008 | 1.023622 |
1 cyl piston set 404112 for Lister - SL Series, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 103.1875 | 65.0875 | 26.9875 | 3 3/16 | 4 1/16 | 2 9/16 | 1 1/16 |
1 cyl piston set 666709 for Fiat - 1585 cc 131
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84 | 77.95 | 38.45 | 22 | 3.307087 | 3.068898 | 1.51378 | 0.866142 |
4 cyl piston set 667234 for Fiat - 1301 cc 131B.000 OHC, 131 Supermirafiori, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.05 | 82.95 | 38.45 | 22 | 2.994094 | 3.265748 | 1.51378 | 0.866142 |
4 cyl piston set 674110 for Simca - 1290 cc OHV Aronde, Rush Engine, CR 7.5 to 1. Rush Super engine CR 8.5 to 1. 1300, 1301 CR 8.3 to 1. 1301GL, 1301LS CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 78.5 | 42 | 22 | 2.913386 | 3.090551 | 1.653543 | 0.866142 |
1 cyl piston set 900033 for Ruston Hornsby - YB Series, Direct injection Diesel, RBP, Air and Water cooled available, 1/2 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 123.825 | 73.0758 | 34.925 | 3 1/2 | 4 7/8 | 2.877 | 1 3/8 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 132.14.00 for Peugeot - 2498 cc XD3, XD3P Engines, 505 GRD/GLD/SRD, Break, Familiale, J9 Pick-Up, CR 23 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 96.42 | 53.92 | 30 | 3.700787 | 3.796063 | 2.122835 | 1.181102 |
