Pistons
Morris
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
6 cyl piston set 12584 for Chrysler, Plymouth - 6 Cyl, CI, CM, CD, De Luxe, CP 8Cyl, CO 6Cyl, 33.8h.p. Heston, Kingston, Airflow 8, Airflow Imperial 8, Airflow Custom, Imperial 8, Airstream 8,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 93.6625 | 50.8 | 21.828125 | 3 1/4 | 3 11/16 | 2 | 55/64 |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
4 cyl piston set 2326 for Ford - 14.9h.p. AF, ABF, C.R. 5.2 to 1, Aluminium version of 2481
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.597 | 89.69375 | 48.41875 | 25.4 | 3.055 | 3 17/32 | 1 29/32 | 1 |
1 cyl piston set 4046 for Villiers - 148cc Longstroke, Two Port, X11C, GY, Two-Stroke with Deflector
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
53 | 91.28125 | 51.59375 | 12.5 | 2.086614 | 3 19/32 | 2 1/32 | 0.492126 |
1 cyl piston set 4635 for Villiers - 98cc Midget, Gudgeon pin parallel to deflector, Two-Stroke
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
50 | 71.4375 | 39.6875 | 12.5 | 1.968504 | 2 13/16 | 1 9/16 | 0.492126 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
4 cyl piston set 5430 for Humber - 12h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 2.73622 | 0 | 0 | 0 |
6 cyl piston set 7382 for Commer - 20.9h.p. N2, N3, N4, PN3, Q2, Q3, Superpoise, 30, 40, 60cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
4 cyl piston set 7664 for Austin - 11.9h.p. 1535cc 12/4 C.R 6.2 to 1 4 cyl 1933-47, 17.9h.p. 2510cc fitted to 16h.p. chassis C.R 6.3 to 1, 6 cyl, Light 12/4, 8/10cwt 4cyl, 15cwt, Ambulance 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.342 | 79.375 | 38.1 | 15.875 | 2.73 | 3 1/8 | 1 1/2 | 5/8 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 7687 for Ford - 8h.p. Model Y, 5cwt, Tug, 40cwt, ring below pin
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 61.11875 | 26.19375 | 17.4625 | 2.23 | 2 13/32 | 1 1/32 | 11/16 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
4 cyl piston set 7765 for Morris - 10h.p. 1292cc Ten Four Series II, III
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
6 cyl piston set 7804 for Morris - 16h.p. 2062cc Oxford
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.5 | 77 | 40.5 | 18 | 2.57874 | 3.031496 | 1.594488 | 0.708661 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 7819 for Rover - 10.8h.p. 21389cc Ten
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.5 | 40.084375 | 78.184375 | 15.875 | 2.61811 | 1 37/64 | 3 5/64 | 5/8 |
4 cyl piston set 8041 for Triumph - 11.8h.p. 1496cc, 1.5 litre Dolomite
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69 | 85 | 45 | 19.05 | 2.716535 | 3.346457 | 1.771654 | 3/4 |
6 cyl piston set 8107 for Commer - 20/70h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 2.952756 | 0 | 0 | 0 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 8282 for Vauxhall - 14h.p. 1781cc, J, C.R 6.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 2.42126 | 0 | 0 | 0 |
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
1 cyl piston set 8684 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Aluminium Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
4 cyl piston set 8788 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston, ring below pin
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
6 cyl piston set 8967 for REO - IA4H, IA4HY, IB4 (After Eng 14000), H/M/Y, IB7M/MY, IC4H/HY, ID4, H/Y, IL5H, 2B, 4/4R/7M, 2D, 4/4M/4MH/4DR, 2H, R/5/5Z, 2J, R/5Z, 2K/2KR, 2L, M/4/4C/7M/7MF, DFX,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.725 | 101.996875 | 82.153125 | 25.003125 | 3 3/8 | 4 1/64 | 3 15/64 | 63/64 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 9178 for Lanchester - 10h.p. 1203 cc Car Nos 15000 to 20050
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.05625 | 38.1 | 15.875 | 2 1/2 | 2 23/32 | 1 1/2 | 5/8 |
1 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 9655 for John Deere - B, BI, BN, BW, BO, BR, Horizontal
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
114.3 | 142.875 | 82.55 | 31.242 | 4 1/2 | 5 5/8 | 3 1/4 | 1.23 |
4 cyl piston set 9984 for Singer - 9.93h.p. 1193cc Super 10, CR 7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.246 | 68 | 33 | 14.2875 | 2.49 | 2.677165 | 1.299213 | 9/16 |
1 cyl piston set 10014 for Humber - 4 cyl 12h.p. 1669cc, 6 cyl 17.97h.p. 2731cc Snipe
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
4 cyl piston set 10336 for Austin - 10.65h.p, A40 Mk. I & II, Devon, Dorset, 1200cc C.R. 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.4685 | 73.025 | 38.1 | 15.875 | 2.5775 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 10931 for Hillman - 1265 cc Minx Mark IV, V, VI, VII, SV, Husky, MkI, CR 6.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.0875 | 73.92 | 39 | 17.4625 | 2 9/16 | 2.910236 | 1.535433 | 11/16 |
8 cyl piston set 11376 for Ford - 21.6h.p. 2158 cc SV Vedette, Comete, V8, 2.2 Litre
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
2 cyl piston set 11564 for Triumph - 649 cc OHV 6T, Thunderbird, CR 7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
71 | 66.278125 | 32.940625 | 17.5 | 2.795276 | 2 39/64 | 1 19/64 | 0.688976 |
1 cyl piston set 11809 for Humber - 29.4 h.p. 4139 cc OHV Super Snipe, Mk IV, Pullman, Imperial
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9 | 112.9538 | 66.675 | 28.575 | 3 1/2 | 4.447 | 2 5/8 | 1 1/8 |
1 cyl piston set 12016 for Ford - 3623 cc SV 3.6 litre, Pilot, V8, CR 6.15 to 1, H lex for 11276
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
6 cyl piston set 12545 for Morris - 14h.p. 1818 cc Morris Series II and III, Fourteen Six, 'Q'
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 70 | 42.5 | 18 | 2.42126 | 2.755906 | 1.673228 | 0.708661 |
4 cyl piston set 12629 for Morris - 1955-6 1489 cc OHV A50 Cambridge. 1957-61, A50, A55. 1956-62 152 series, Omnivan, Omnitruck, 15 Cwt. Omnicoach, 10 Cwt. Van, J4 10/15 Cwt. Low Comp CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 12756 for Austin - 23.44h.p. 2639.4cc O.H.V. A90 Westminster 2.6 Lit/ A95 Low Comp. CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 87.3125 | 47.625 | 22.225 | 3 1/8 | 3 7/16 | 1 7/8 | 7/8 |
4 cyl piston set 13251 for Ford (American) - 1941-2 4Cyl 1NC/2NC/1ND/2ND/1NY/2NY, 1/2 - 1 Ton. 1939-47 32.5HP (95/100h.p. V8), (09/19/29/59/69/79/99)C, (09/29/69/79/99)D,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.9625 | 80.9625 | 45.24375 | 19.05 | 3 3/16 | 3 3/16 | 1 25/32 | 3/4 |
6 cyl piston set 13542 for Morris - 23.44h.p. 2639.4cc OHV Isis, 2.6 Litre, Low Comp, CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 87.3125 | 47.625 | 22.225 | 3 1/8 | 3 7/16 | 1 7/8 | 7/8 |
4 cyl piston set 14136 for MG - 1250 cc OHV Midget, 1 1/4 Litre, Series TB, TC, TD, TF, Y, YA, YB
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.5 | 73 | 45 | 18 | 2.61811 | 2.874016 | 1.771654 | 0.708661 |
4 cyl piston set 14370 for Standard - 1009 cc SV Flying Eight, CR 6.7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.7 | 73.025 | 38.1 | 15.875 | 2.232283 | 2 7/8 | 1 1/2 | 5/8 |
1 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 15659 for Simca - 1090 cc OHV Etoile 6CV, Rush Engine CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
68 | 78.5 | 42 | 20 | 2.677165 | 3.090551 | 1.653543 | 0.787402 |
4 cyl piston set 16201 for MG - 1798 cc OHV MGB1800, CR 8.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.2513 | 76.99375 | 42.06875 | 19.05 | 3.1595 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16205 for Ford - 997 cc OHV Anglia, Thames 5-7 Cwt, 105E Engine, Perfect 107E Engine, CR 8.9 to 1, Thames 5-7 Cwt 307E Engine CR 7.5 to 1. 1198 cc OHV Anglia Super, Cortina,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.9498 | 77.1398 | 38.89375 | 20.6375 | 3.187 | 3.037 | 1 17/32 | 13/16 |
4 cyl piston set 16309 for Wolseley - 998 cc OHV Hornet, CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 65.8368 | 34.0868 | 15.875 | 2.542 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 16422 for Volkswagen - 1493 cc OHV 1500S, RWD Air Cooled, 341 motor CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 88 | 45 | 22 | 3.267717 | 3.464567 | 1.771654 | 0.866142 |
2 cyl piston set 16993 for Honda - 125 cc OHC Benly C92, CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
44 | 53 | 30 | 14 | 1.732283 | 2.086614 | 1.181102 | 0.551181 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7494 | 75.565 | 37.6174 | 20 | 3.061 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
1 cyl piston set 17363 for Audi - 1696 cc O.H.V. Audi 80/F103, 1700s-103 Engine. CR 11 to 1, SSD
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 72.5 | 43.5 | 24 | 3.149606 | 2.854331 | 1.712598 | 0.944882 |
4 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17560 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17570 for Bedford - 1975 cc OHC CF 22/25/35 cwt. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95.25 | 81.8642 | 43.8658 | 25.4 | 3 3/4 | 3.223 | 1.727 | 1 |
4 cyl piston set 17840 for Saab, Triumph - 1709 cc OHC, CR 8.8 to 1 to Engine JBB7509
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 64.5668 | 34.0868 | 20.6375 | 2.542 | 2.542 | 1.342 | 13/16 |
1 cyl piston set 18246 for BSA - 150 cc F15 industrial - RBP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.9859 | 57.5564 | 35.8902 | 14.2875 | 2.5585 | 2.266 | 1.413 | 9/16 |
1 cyl piston set 18517 for Austin - 1071cc OHV Mini Cooper S CR 9 to 1/1275 cc OHV Mini Cooper S CR 9.75 to 1/ Healey Sprite MkIV 9.75 to 1/1300GT CR 10.96 to 1 (Forged Piston)
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 18679 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1, 2733E Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18746 for Moskvitch - 1478 cc OHC 412 Saloon, 427 Estate, 434 Van, 412 Engine, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81.98 | 92 | 58 | 22 | 3.227559 | 3.622047 | 2.283465 | 0.866142 |
4 cyl piston set 19105 for Hillman - 875 cc OHC Imp, Super Imp, Husky, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.2564 | 52.0573 | 26.67 | 15.875 | 2.766 | 2.0495 | 1.05 | 5/8 |
1 cyl piston set 19231 for Bedford - 3519 cc OHV 214 Engine 1 1/4 - 8 ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.725 | 85.725 | 46.1264 | 20.6375 | 3 3/8 | 3 3/8 | 1.816 | 13/16 |
1 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 19472 for Chrysler - 1598 cc OHV Avenger 1600 GLS/TC. Low Comp CR 8.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19724 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7494 | 75.6412 | 37.6936 | 20 | 3.061 | 2.978 | 1.484 | 0.787402 |
4 cyl piston set 19906 for Triumph - 1998 cc OHC TR7, CR 8 to 1, USA Version
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90.28684 | 70 | 34.1 | 23.8125 | 3.5546 | 2.755906 | 1.34252 | 15/16 |
6 cyl piston set 20108 for Ford - 1996 cc OHV Transit V4, CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 95.25 | 46.1391 | 20.6375 | 3.6869 | 3 3/4 | 1.8165 | 13/16 |
4 cyl piston set 20204 for Audi - 1093 cc. Audi 50/GLS/LS. CR 8/8.2 to 1, Pyrostrut design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 67.2 | 40.3 | 20 | 2.73622 | 2.645669 | 1.586614 | 0.787402 |
1 cyl piston set 20297 for Rover - 2597 cc OHC 2.6 Litre CR 9.25 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81 | 63.1 | 35.2 | 23.8125 | 3.188976 | 2.484252 | 1.385827 | 15/16 |
4 cyl piston set 20397 for Austin, Morris - 1098 cc Austin A40 MkII 1100 OHV/Allegro 1100 De Luxe, Morris 1100/Minor 1000 OHV. 'A' Series Engine CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 58.0517 | 30.3276 | 15.86738 | 2.542 | 2.2855 | 1.194 | 0.6247 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20888 for Volkswagen - 1984 cc 2 Litre transporter, LT28-281CH/283, CH285/CH; LT31-281CH/283, CH285/CH, LT35
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.51 | 77.6 | 40.85 | 24 | 3.405906 | 3.055118 | 1.608268 | 0.944882 |
1 cyl piston set 21138 for Yamaha - YZ125 J
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56 | 56 | 32 | 16 | 2.204724 | 2.204724 | 1.259843 | 0.629921 |
4 cyl piston set 21776 for Suzuki - 970 cc F10A Engine, OHC Jimny SJ410/Q/V, 4WD, 110S40FK, 1000SJ40VC CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.5 | 2.57874 | 0 | 0 | 0 |
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 350024 for Ford - 4D 250 Cubic inches, D Series, 2701E Engine Vertical, 2706E Inclined 4 cylinder. 6D 360 cubic inches, D series 2704E Vertical, 2709 inclined 6cyl, Diesel. CR...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
104.775 | 118.26875 | 71.040625 | 34.925 | 4 1/8 | 4 21/32 | 2 51/64 | 1 3/8 |
4 cyl piston set 350176 for Daimler Benz - 3782 cc L408D/508D/608D, 709, 808, 809, Bus, 0309, D-330, Unimog, U54/403, U66/403, U72/800/900, MB-Trac65/70/700/800, Diesel CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
97 | 105.2 | 65.25 | 36 | 3.818898 | 4.141732 | 2.568898 | 1.417323 |
1 cyl piston set 350268 for Petter - PJ MkII, PJW Ser, Air and Water cooled Multi Cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
96.8756 | 105.9942 | 63.59906 | 30 | 3.814 | 4.173 | 2.5039 | 1.181102 |
1 cyl piston set 350382 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600. Also BSD333H/BSD444 Engine, Direct injection 4610, 4610SU Tractors, 6610, 6710...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
4 cyl piston set 350979 for Ford - 1753 cc 59h.p, Courier 1.8D Van, Escort 1.8D (35/55 Combi Van, 40/60/55/75 Van, GLX/Ghia/L/LX/L Business, Popular, Encore, Popular Plus, LD/GLD), Fiesta 1.8D...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.5 | 73.5 | 45.7 | 26 | 3.248031 | 2.893701 | 1.799213 | 1.023622 |
1 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
4 cyl piston set 665712 for Fiat - 1089 cc 1100/103, Engine type 103, CR 6.7 to 1. 1100R Engine Type 103H000, CR 8.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
4 cyl piston set 667061 for Fiat - 4 cyl, 1049 cc 127AB.OC.O and 127AB.ON.O Engines, OHC. 127-1050 CL, 127 Fiorino, 147 Brazil, 60L Ritmo, CR 9.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 76.05 | 36.05 | 22 | 2.992126 | 2.994094 | 1.419291 | 0.866142 |
2 cyl piston set 668051 for Fiat - 1585 cc, 131A1/AF1/B1 Engines, 1978/91; 131 1600, 131 Mirafiori L, LC, Panorama 1300, 131 Supermirafiori, Supermirafiori, 1976/81; 242/15 Van, 1974/8; 131...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84 | 77.95 | 38.45 | 22 | 3.307087 | 3.068898 | 1.51378 | 0.866142 |
4 cyl piston set 768120 for Simca - 1118 cc 1100G, 1100GLS, 350 Engine. CR 9.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
1 cyl piston set 11592 JP for Ford - 4 cyl 15.63h.p. 1508 cc OHV Consul, 6cyl 23.44h.p. 2262 cc OHV Zephyr, Zodiac RBP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.4004 | 82.55 | 47.7012 | 20.6375 | 3.126 | 3 1/4 | 1.878 | 13/16 |
4 cyl piston set 129.14.07 for Peugeot - 2304 cc XD2-XD2P-XD94 Engines, 504 GLD/Berline/Familiale, 505 GRD/SRD, J7 PX/PY/PZ, J9, CR 22.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
94 | 99.9 | 57.42 | 28 | 3.700787 | 3.933071 | 2.26063 | 1.102362 |
