Pistons

        Morris
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
6 cyl piston set 12584 for Chrysler, Plymouth - 6 Cyl, CI, CM, CD, De Luxe, CP 8Cyl, CO 6Cyl, 33.8h.p. Heston, Kingston, Airflow 8, Airflow Imperial 8, Airflow Custom, Imperial 8, Airstream 8,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 93.6625 | 50.8 | 21.828125 | 3 1/4 | 3 11/16 | 2 | 55/64 |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
4 cyl piston set 2326 for Ford - 14.9h.p. AF, ABF, C.R. 5.2 to 1, Aluminium version of 2481
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.597 | 89.69375 | 48.41875 | 25.4 | 3.055 | 3 17/32 | 1 29/32 | 1 |
1 cyl piston set 4046 for Villiers - 148cc Longstroke, Two Port, X11C, GY, Two-Stroke with Deflector
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 53 | 91.28125 | 51.59375 | 12.5 | 2.086614 | 3 19/32 | 2 1/32 | 0.492126 |
1 cyl piston set 4635 for Villiers - 98cc Midget, Gudgeon pin parallel to deflector, Two-Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 71.4375 | 39.6875 | 12.5 | 1.968504 | 2 13/16 | 1 9/16 | 0.492126 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
4 cyl piston set 5430 for Humber - 12h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 2.73622 | 0 | 0 | 0 | |||
6 cyl piston set 7382 for Commer - 20.9h.p. N2, N3, N4, PN3, Q2, Q3, Superpoise, 30, 40, 60cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
4 cyl piston set 7664 for Austin - 11.9h.p. 1535cc 12/4 C.R 6.2 to 1 4 cyl 1933-47, 17.9h.p. 2510cc fitted to 16h.p. chassis C.R 6.3 to 1, 6 cyl, Light 12/4, 8/10cwt 4cyl, 15cwt, Ambulance 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.342 | 79.375 | 38.1 | 15.875 | 2.73 | 3 1/8 | 1 1/2 | 5/8 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 7687 for Ford - 8h.p. Model Y, 5cwt, Tug, 40cwt, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 61.11875 | 26.19375 | 17.4625 | 2.23 | 2 13/32 | 1 1/32 | 11/16 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
4 cyl piston set 7765 for Morris - 10h.p. 1292cc Ten Four Series II, III
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
6 cyl piston set 7804 for Morris - 16h.p. 2062cc Oxford
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77 | 40.5 | 18 | 2.57874 | 3.031496 | 1.594488 | 0.708661 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 7819 for Rover - 10.8h.p. 21389cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 40.084375 | 78.184375 | 15.875 | 2.61811 | 1 37/64 | 3 5/64 | 5/8 |
4 cyl piston set 8041 for Triumph - 11.8h.p. 1496cc, 1.5 litre Dolomite
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69 | 85 | 45 | 19.05 | 2.716535 | 3.346457 | 1.771654 | 3/4 |
6 cyl piston set 8107 for Commer - 20/70h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 2.952756 | 0 | 0 | 0 | |||
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 8282 for Vauxhall - 14h.p. 1781cc, J, C.R 6.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 2.42126 | 0 | 0 | 0 | |||
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
1 cyl piston set 8684 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
4 cyl piston set 8788 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
6 cyl piston set 8967 for REO - IA4H, IA4HY, IB4 (After Eng 14000), H/M/Y, IB7M/MY, IC4H/HY, ID4, H/Y, IL5H, 2B, 4/4R/7M, 2D, 4/4M/4MH/4DR, 2H, R/5/5Z, 2J, R/5Z, 2K/2KR, 2L, M/4/4C/7M/7MF, DFX,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 101.996875 | 82.153125 | 25.003125 | 3 3/8 | 4 1/64 | 3 15/64 | 63/64 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 9178 for Lanchester - 10h.p. 1203 cc Car Nos 15000 to 20050
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.05625 | 38.1 | 15.875 | 2 1/2 | 2 23/32 | 1 1/2 | 5/8 |
1 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 9655 for John Deere - B, BI, BN, BW, BO, BR, Horizontal
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 114.3 | 142.875 | 82.55 | 31.242 | 4 1/2 | 5 5/8 | 3 1/4 | 1.23 |
4 cyl piston set 9984 for Singer - 9.93h.p. 1193cc Super 10, CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.246 | 68 | 33 | 14.2875 | 2.49 | 2.677165 | 1.299213 | 9/16 |
1 cyl piston set 10014 for Humber - 4 cyl 12h.p. 1669cc, 6 cyl 17.97h.p. 2731cc Snipe
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
4 cyl piston set 10345 for Perkins - PA, PB, P4, 4192, 14.7h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 3.501 | 0 | 0 | 0 | |||
1 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 10931 for Hillman - 1265 cc Minx Mark IV, V, VI, VII, SV, Husky, MkI, CR 6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.0875 | 73.92 | 39 | 17.4625 | 2 9/16 | 2.910236 | 1.535433 | 11/16 |
1 cyl piston set 11433 for International - Farmall M, MV, I6, IU6, O6, OS6, T6, W6, Power Unit U6, High Comp for 9591
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 146.05 | 90.4875 | 33.3375 | 3 7/8 | 5 3/4 | 3 9/16 | 1 5/16 |
4 cyl piston set 11581 for Morris - 6 cyl 14.9h.p. Major QX, Oxford, Fifteen Six. 4 Cyl Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
6 cyl piston set 11848 for Fordson - 3610 cc OHV Major Tractor, Vaporising Oil, CR 4.35 to 1, 24.8h.p. OHV Cost Cutter, 1 1/2 - 4 Ton, Petrol
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 99.9998 | 117.9576 | 71.0438 | 31.75 | 3.937 | 4.644 | 2.797 | 1 1/4 |
1 cyl piston set 12064 for AEC - A312, 5.123 Lit. 4Cyl. 1685cc. AV470/AH470/Regent MkV/Reliance/Mercury/8 ton/7.75 Lit, 6 Cyl, Direct injection Diesel, C.R. 16 to 1 - RBP, H'lex Tin Plated
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 112 | 152.2476 | 91.9226 | 40 | 4.409449 | 5.994 | 3.619 | 1.574803 |
4 cyl piston set 12455 for Hudson, Nash - 1932-39, 3475 cc Big 6, Custom 6, Terra Plane 6. 4168 cc Great 8, Pacemaker 8, Special 8, Deluxe 8, Custom 8. Late 1939-56, 3310 cc SV Super 6, Commodore...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 80.9625 | 42.8625 | 19.05 | 3 8.8817841970013E-16/2 | 3 3/16 | 1 11/16 | 3/4 |
6 cyl piston set 12545 for Morris - 14h.p. 1818 cc Morris Series II and III, Fourteen Six, 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 70 | 42.5 | 18 | 2.42126 | 2.755906 | 1.673228 | 0.708661 |
4 cyl piston set 12650 for Standard, Triumph - 948 cc OHV Ten, Pennant, 6 cwt Van, Atlas 10/12 Cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 66.1 | 38.1 | 15.875 | 2.480315 | 2.602362 | 1 1/2 | 5/8 |
6 cyl piston set 12768 for Austin - 4 cyl 2660 cc OHV Champ, 5 cwt. 6 cyl 3993 cc OHV 4 Litre , Loadstar, 2-5 ton/ 4x4 1 ton, 6 cyl.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 13251 for Ford (American) - 1941-2 4Cyl 1NC/2NC/1ND/2ND/1NY/2NY, 1/2 - 1 Ton. 1939-47 32.5HP (95/100h.p. V8), (09/19/29/59/69/79/99)C, (09/29/69/79/99)D,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 80.9625 | 45.24375 | 19.05 | 3 3/16 | 3 3/16 | 1 25/32 | 3/4 |
4 cyl piston set 13556 for Austin - 948 cc O.H.V. A35, A40 Healey Sprite, Low Comp CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 14136 for MG - 1250 cc OHV Midget, 1 1/4 Litre, Series TB, TC, TD, TF, Y, YA, YB
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 73 | 45 | 18 | 2.61811 | 2.874016 | 1.771654 | 0.708661 |
4 cyl piston set 14370 for Standard - 1009 cc SV Flying Eight, CR 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.7 | 73.025 | 38.1 | 15.875 | 2.232283 | 2 7/8 | 1 1/2 | 5/8 |
1 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 16309 for Wolseley - 998 cc OHV Hornet, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.8368 | 34.0868 | 15.875 | 2.542 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 17012 for Austin, Morris - 1622 cc OHV Austin A60, Morris Oxford, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17570 for Bedford - 1975 cc OHC CF 22/25/35 cwt. CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 81.8642 | 43.8658 | 25.4 | 3 3/4 | 3.223 | 1.727 | 1 |
4 cyl piston set 18262 for Triumph - 1296 cc OHV 1300 CR 8.5 to 1, Spitfire CR 9 to 1 to Engine RD19476
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 18519 for Austin - 948cc OHV Healey Sprite MkI. CR 9.35 to 1/ MkII 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 18680 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18753 for Ford - 1593 cc OHC Cortina 1600 GT, Capri 1600/GT, Cortina 1600 L, Cortina 1600 XL, CR 9.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.65 | 73.1 | 41.2 | 24 | 3.450787 | 2.877953 | 1.622047 | 0.944882 |
4 cyl piston set 19105 for Hillman - 875 cc OHC Imp, Super Imp, Husky, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.2564 | 52.0573 | 26.67 | 15.875 | 2.766 | 2.0495 | 1.05 | 5/8 |
1 cyl piston set 19270 for Standard, Triumph - 1961/3 - Standard OHV 2 litre, Vanguard Six, E30/1, CR 8 to 1. 1964/9 - Triumph 2000, CR 8.5 to 1. 1965/70 2000 to Engine 50000, CR 9 to 1. 1967/70 -...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 74.1426 | 38.1508 | 20.6375 | 2.9405 | 2.919 | 1.502 | 13/16 |
1 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 19557 for Audi - 1296 cc. Audi 60/80/80L. CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 77.5 | 45.5 | 22 | 2.952756 | 3.051181 | 1.791339 | 0.866142 |
4 cyl piston set 19724 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7494 | 75.6412 | 37.6936 | 20 | 3.061 | 2.978 | 1.484 | 0.787402 |
1 cyl piston set 19913 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Popular 1300, Escort 8 cwt van, 751M Engine, Low Comp. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20118 for Austin - 1695 cc Leyland 'O' series engine - Sherpa 200/230/250/255. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 72.04964 | 42.09796 | 20.6375 | 3.3245 | 2.8366 | 1.6574 | 13/16 |
4 cyl piston set 20204 for Audi - 1093 cc. Audi 50/GLS/LS. CR 8/8.2 to 1, Pyrostrut design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 67.2 | 40.3 | 20 | 2.73622 | 2.645669 | 1.586614 | 0.787402 |
6 cyl piston set 20316 for Ford - 2.3 litre HF23 V6 Engine, OHV 20M, 2300S, 21M/TS 2300 S, 20M/RS, Cortina GL/S/Ghia, Taunus 2300 GXL/S/Sport/Coupe/Ghia, Capri 2300 GT/R, Capri II 2300 GT/S//Ghia,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 24 | 3.543307 | 0 | 0 | 0.944882 | ||
4 cyl piston set 20398 for Austin, Morris - 1098 cc 'A' Series Engine OHV 1100/Minor 1000/ 6 cwt Van/Marina 7 cwt Van, Low Comp CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.0517 | 30.3276 | 15.875 | 2.542 | 2.2855 | 1.194 | 5/8 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
4 cyl piston set 21145 for Honda - 498 cc XL500, S/SZ/Z/A
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 89 | 65.2 | 29.2 | 21 | 3.503937 | 2.566929 | 1.149606 | 0.826772 |
4 cyl piston set 21813 for Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910, TLJ910)....
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
6 cyl piston set 164505 for Leyland - 5.76 Litre, 0350 Mk II, Comet 90, Comet 100, Tiger Club, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.62718 | 132.715 | 81.915 | 33.02 | 3.9617 | 5.225 | 3.225 | 1.3 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
1 cyl piston set 350067 for Ford - 4D 240 cubic inches, D Series, 2701E Vertical, 2706E Inclined. 6D 360 cubic inches, D Series 2704E Vertical, 2709E Inclined. Diesel, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.11 | 71.0311 | 34.925 | 4 1/8 | 4.65 | 2.7965 | 1 3/8 |
1 cyl piston set 350188 for David Brown - DB1410, DB1412, AD 4/55 Engines, Turbocharged, Diesel, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
6 cyl piston set 350227 for Ford - 6571 cc 401 Cu. In, 6 cyl Dexta Tractor, Series 6Y, 8000, Series 7A, 8600, 8700. CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 126.9746 | 68.1228 | 38.1 | 4.2007 | 4.999 | 2.682 | 1 1/2 |
1 cyl piston set 350277 for Leyland - 4 Cyl, 3.77 Litre Leyland 4/98 Series, 6 cyl, 5.65 Litre, 6/98 Series, Turbocharged Diesel, Al Fin Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98 | 116.307 | 68.25 | 36.5125 | 3.858268 | 4.579016 | 2.687008 | 1 7/16 |
4 cyl piston set 350318 for Opel - 2068 cc 2.1D Engine, Blitz 2.1D, Rekord 2.1D, L, Berlina, Caravan, CR 21/22/24 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 88.75 | 53.8 | 28 | 3.464567 | 3.494094 | 2.11811 | 1.102362 |
2 cyl piston set 350385 for Bedford - 8200 cc 500 phase 1 engine. Direct injection TM Series 7400000 -> Al fin design for 350262
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.8875 | 122.4788 | 75.82916 | 44.45 | 4 9/16 | 4.822 | 2.9854 | 1 3/4 |
4 cyl piston set 350449 for Mazda - 2184 cc R2 Engine, E2200 Van, Pick-Up, Crew Cab. CR 22.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 86.25 | 47.25 | 25 | 3.385827 | 3.395669 | 1.860236 | 0.984252 |
4 cyl piston set 403801 for Alfa Romeo - 1186 cc 301.00 Engine, Alfasud L, N, SM, Super 1.2, Arna 1.2. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
1 cyl piston set 483506 for Lister - SR Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 103.1875 | 65.0875 | 29.36875 | 3 1/2 | 4 1/16 | 2 9/16 | 1 5/32 |
1 cyl piston set 586006 for David Brown - 3 cyl 2395 cc 770, 4cyl 3195 cc 990, Direct Injection Diesel, CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 111.9124 | 66.7258 | 31.75 | 3.9388 | 4.406 | 2.627 | 1 1/4 |
6 cyl piston set 664098 for Fiat - 2054 cc OHV 2100 Engine type 114, C.R 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 85.75 | 48.5 | 22 | 3.031496 | 3.375984 | 1.909449 | 0.866142 |
4 cyl piston set 665946 for Fiat - 1438 cc 124 Coupe 2nd Series, 124 Sport, 125 2nd Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 81.45 | 41.95 | 22 | 3.149606 | 3.206693 | 1.651575 | 0.866142 |
4 cyl piston set 666532 for Alfa Romeo - Alfasud Ti, Super 1.2/S/SC/Arna 1.2Sl, Piston Pin press fit into con-rod
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
4 cyl piston set 667509 for Alfa Romeo, Nissan - 1186 cc 301.00 Engine, Alfa Romeo Arna 1.2SI, Nissan Cherry 1.2, CR 9.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
2 cyl piston set 668051 for Fiat - 1585 cc, 131A1/AF1/B1 Engines, 1978/91; 131 1600, 131 Mirafiori L, LC, Panorama 1300, 131 Supermirafiori, Supermirafiori, 1976/81; 242/15 Van, 1974/8; 131...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84 | 77.95 | 38.45 | 22 | 3.307087 | 3.068898 | 1.51378 | 0.866142 |
4 cyl piston set 032.12.08 for Peugeot - 1124 cc XW7 Engine, OHC 104Z/ZR/ZA/GL/GR, 205 GL/GR/XL/XR. CR 9.7/10.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 73.5 | 40.05 | 19.5 | 2.834646 | 2.893701 | 1.576772 | 0.767717 |
1 cyl piston set 11592 JP for Ford - 4 cyl 15.63h.p. 1508 cc OHV Consul, 6cyl 23.44h.p. 2262 cc OHV Zephyr, Zodiac RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.4004 | 82.55 | 47.7012 | 20.6375 | 3.126 | 3 1/4 | 1.878 | 13/16 |
4 cyl piston set 18645 JP for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
