Pistons
4 cyl piston set 16844 for Vauxhall - 1964/6 1057 cc OHV Viva, CR 8.5 to 1 (7.5 when thick gasket fitted). 1966 OHV Viva 90, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.295 | 75.565 | 37.6174 | 2.925 | 2.975 | 1.481 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Alfa Romeo - c.r. 9
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84 | 67.5 | 34.5 | 21 | 3.307087 | 2.65748 | 1.358268 | 0.826772 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
6 cyl piston set 2366 for Commer - 40h.p. G2, 6TK, Invador, Corinthian
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 83.34375 | 39.6875 | 19 | 3.149606 | 3 9/32 | 1 9/16 | 0.748031 |
1 cyl piston set 4238 for Wolseley - 12.08h.p. 1271cc Hornet, High Comp. C.R 6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57 | 70.64375 | 39.6875 | 14.2875 | 2.244094 | 2 25/32 | 1 9/16 | 9/16 |
4 cyl piston set 7164 for Coventry Climax - 10h.p. 1122cc SV & OHV Type I, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 77.7875 | 36.5125 | 19.05 | 3 1/4 | 3 1/16 | 1 7/16 | 3/4 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
1 cyl piston set 8057 for Morris - 8h.p. 918cc Eight, series E
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57 | 63.5 | 28 | 15 | 2.244094 | 2 1/2 | 1.102362 | 0.590551 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
4 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
4 cyl piston set 9036 for Ford - V8 22h.p. 2227cc Utility, V8, 60h.p. Export, 74, 82A, 922A, 022A C.R.6.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
6 cyl piston set 9327 for Vauxhall - 25h.p. 3215 cc from Engine No G8086
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81.94 | 85.725 | 41.275 | 25.146 | 3.225984 | 3 3/8 | 1 5/8 | 0.99 |
4 cyl piston set 10007 for Austin - 15.99h.p. 2199cc OHV Sixteen to engine 1400 C.R 6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 98.425 | 47.625 | 22.225 | 3 1/8 | 3 7/8 | 1 7/8 | 7/8 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
1 cyl piston set 10648 for Austin - 28.8 h.p. 3993 cc O.H.V. 4 litre Loadstar, 2-5 ton, 6 Cyl. Austin Champ 18.9HP, 2660 cc 4 Cyl.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 11479 for Commer - 16h.p. 2266 cc SV Q25, Super-poise, 25 cwt. Van
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.7339 | 93 | 51 | 24 | 3.1785 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12503 for Ford - 8h.p. 933 cc SV 5 Cwt, H'lex
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 65.2526 | 31.115 | 17.4625 | 2.23 | 2.569 | 1.225 | 11/16 |
4 cyl piston set 12650 for Standard, Triumph - 948 cc OHV Ten, Pennant, 6 cwt Van, Atlas 10/12 Cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63 | 66.1 | 38.1 | 15.875 | 2.480315 | 2.602362 | 1 1/2 | 5/8 |
6 cyl piston set 13337 for Austin - 28.8h.p. 3993 cc O.H.V. 4 Lit Princess MarkIV, CR 7.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
6 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 16312 for Fiat - 1089 cc OHV 1100/103TV, Three Ring Design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
1 cyl piston set 16639 for Vauxhall - 3293 cc OHV Velox, Cresta, Viscount, CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92.075 | 77.9272 | 44.45 | 21.9964 | 3 5/8 | 3.068 | 1 3/4 | 0.866 |
1 cyl piston set 17119 for Opel - Kadett S coupe, 1000S Engine, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
72 | 76 | 38 | 20 | 2.834646 | 2.992126 | 1.496063 | 0.787402 |
6 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
2 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 17482 for Datsun - 4 cyl 988 cc OHV 1000. CR 8 to 1. 1189 cc OHV Bluebird 1200, El Engine, 1299 cc OHV Bluebird 1300, P411, J Engine, CR 8.2 to 1. 6 cyl 1973 cc OHV Cedric De...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 67.5 | 32.5 | 17.4498 | 2.874016 | 2.65748 | 1.279528 | 0.687 |
2 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
1 cyl piston set 17568 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.7 | 83.312 | 45.3136 | 25.4 | 3.374016 | 3.28 | 1.784 | 1 |
4 cyl piston set 17571 for Vauxhall - 1975 cc OHC Victor 2000 SL, Viva GT, VX Four Ninety, Firenza 2000 SL, Low Comp CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95.25 | 81.0514 | 43.053 | 25.4 | 3 3/4 | 3.191 | 1.695 | 1 |
4 cyl piston set 18111 for Hillman - 875 cc OHC Imp, Super Imp, Husky C.R 10 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
67.98564 | 52.1843 | 26.797 | 15.875 | 2.6766 | 2.0545 | 1.055 | 5/8 |
4 cyl piston set 18262 for Triumph - 1296 cc OHV 1300 CR 8.5 to 1, Spitfire CR 9 to 1 to Engine RD19476
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 18519 for Austin - 948cc OHV Healey Sprite MkI. CR 9.35 to 1/ MkII 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 18643 for Ford - 940 cc OHV Export Escort 940, CR 9.5 to 1, Uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18680 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18683 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18753 for Ford - 1593 cc OHC Cortina 1600 GT, Capri 1600/GT, Cortina 1600 L, Cortina 1600 XL, CR 9.2 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.65 | 73.1 | 41.2 | 24 | 3.450787 | 2.877953 | 1.622047 | 0.944882 |
4 cyl piston set 18802 for Austin - 1798 cc OHV 1800, 1800 HL, 1800 MkII/MkIII CR 9 to 1, 1800S MkII CR 9.5 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.23733 | 61.1124 | 42.164 | 20.6375 | 3.15895 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19105 for Hillman - 875 cc OHC Imp, Super Imp, Husky, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.2564 | 52.0573 | 26.67 | 15.875 | 2.766 | 2.0495 | 1.05 | 5/8 |
2 cyl piston set 19131 for Ford - 1969-71 1996 cc OHV Capri 2000GT, V4, CR 8.9 to 1. 1972 onwards 2994 cc OHV Capri, Consul GT, Granada, Granada GXL, 3 litre V6, CR 8.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 95.25 | 46.1391 | 23.8125 | 3.6869 | 3 3/4 | 1.8165 | 15/16 |
1 cyl piston set 19270 for Standard, Triumph - 1961/3 - Standard OHV 2 litre, Vanguard Six, E30/1, CR 8 to 1. 1964/9 - Triumph 2000, CR 8.5 to 1. 1965/70 2000 to Engine 50000, CR 9 to 1. 1967/70 -...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.6887 | 74.1426 | 38.1508 | 20.6375 | 2.9405 | 2.919 | 1.502 | 13/16 |
4 cyl piston set 19298 for Ford - 5 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
1 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
Mini Cooper
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 19557 for Audi - 1296 cc. Audi 60/80/80L. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 77.5 | 45.5 | 22 | 2.952756 | 3.051181 | 1.791339 | 0.866142 |
4 cyl piston set 19657 for Toyota - 1591 cc 7R Engine, Corona Mk II, 1600 DX. 1707 cc 6R Engine, Corona Mk II, Van DX MkII for LPG. 1858 cc 8R Engine, Corona MkII, Hard Top 1900 GL, 8R-C
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86 | 84.75 | 39.75 | 22 | 3.385827 | 3.336614 | 1.564961 | 0.866142 |
4 cyl piston set 19724 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7494 | 75.6412 | 37.6936 | 20 | 3.061 | 2.978 | 1.484 | 0.787402 |
4 cyl piston set 19743 for Mitsubishi - 1439 cc 4G33 Engine, OHC 1400 Colt, Lancer, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 69.7 | 32.7 | 19 | 2.874016 | 2.744094 | 1.287402 | 0.748031 |
1 cyl piston set 19913 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Popular 1300, Escort 8 cwt van, 751M Engine, Low Comp. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
2 cyl piston set 19938 for Honda - 249 cc OHC CB250, CB250K2, CB250K3, CB250K4, CB250G5, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56 | 62.5 | 32.1 | 15 | 2.204724 | 2.46063 | 1.26378 | 0.590551 |
1 cyl piston set 20118 for Austin - 1695 cc Leyland 'O' series engine - Sherpa 200/230/250/255. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 72.04964 | 42.09796 | 20.6375 | 3.3245 | 2.8366 | 1.6574 | 13/16 |
4 cyl piston set 20139 for Triumph - 1493 cc OHV 1500, CR 8.5 to 1. OHV 1500, 1500TC, Spitfire 1500, Dolomite 1500, 1500HL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 58.0898 | 32.6898 | 20.6375 | 2.8995 | 2.287 | 1.287 | 13/16 |
4 cyl piston set 20204 for Audi - 1093 cc. Audi 50/GLS/LS. CR 8/8.2 to 1, Pyrostrut design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 67.2 | 40.3 | 20 | 2.73622 | 2.645669 | 1.586614 | 0.787402 |
4 cyl piston set 20228 for Datsun - 1288 cc B210 A13 Engine.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 67.5 | 32.6 | 17.452 | 2.874016 | 2.65748 | 1.283465 | 0.687087 |
6 cyl piston set 20316 for Ford - 2.3 litre HF23 V6 Engine, OHV 20M, 2300S, 21M/TS 2300 S, 20M/RS, Cortina GL/S/Ghia, Taunus 2300 GXL/S/Sport/Coupe/Ghia, Capri 2300 GT/R, Capri II 2300 GT/S//Ghia,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90 | 24 | 3.543307 | 0 | 0 | 0.944882 |
1 cyl piston set 20350 for Suzuki - 2 Cyl 398 cc DOHC GS400, GS400C, GS400EC, GS400N, GS400EN. 4 Cyl 750 cc DOHC GS750, C/DC/N/DN
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65 | 63.7 | 35.8 | 16 | 2.559055 | 2.507874 | 1.409449 | 0.629921 |
4 cyl piston set 20398 for Austin, Morris - 1098 cc 'A' Series Engine OHV 1100/Minor 1000/ 6 cwt Van/Marina 7 cwt Van, Low Comp CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 58.0517 | 30.3276 | 15.875 | 2.542 | 2.2855 | 1.194 | 5/8 |
4 cyl piston set 20548 for Ford - 1098 cc OHV Escort 6-8 cwt Van, Escorty 1100, Popular 1100, 751M Engine High Comp, CR 9 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20747 for Mini - 1275 cc OHV Cooper S, CR 9.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
4 cyl piston set 21075 for Austin - 1695 cc 'O' Series OHC Ambassador 1.7L/HL, Princess 1700L/HL/HLS, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 73.37044 | 43.41876 | 20.64258 | 3.3245 | 2.8886 | 1.7094 | 0.8127 |
4 cyl piston set 21145 for Honda - 498 cc XL500, S/SZ/Z/A
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
89 | 65.2 | 29.2 | 21 | 3.503937 | 2.566929 | 1.149606 | 0.826772 |
4 cyl piston set 21262 for Vauxhall - 1598 cc 1.6N, 1.6S Engine, OHC Astra 1600L, GL, SR, Belmont 1600L, GL, GLS, Cavalier, L, GL, LX, SR, GLS. CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 72 | 40.05 | 23 | 3.149606 | 2.834646 | 1.576772 | 0.905512 |
4 cyl piston set 21813 for Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910, TLJ910)....
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
4 cyl piston set 22304 for Opel - 1598 cc X1.6SZ Engine, Single Point Injection, Astra GL/GLS/CDX/Season/Club, CR 10.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79 | 48 | 28.05 | 18 | 3.110236 | 1.889764 | 1.104331 | 0.708661 |
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
4 cyl piston set 230011 for Ferguson - 2259 cc OHV 35 Diesel CR 20 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.1756 | 98.2599 | 60.198 | 28.575 | 3.314 | 3.8685 | 2.37 | 1 1/8 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
4 cyl piston set 350051 for Ford - 4 cyl 2358 cc Transit 75/80/90/100/115/125/130/150/160/175/190, Vans 100, 150. York 2.4 litre. 3537 cc A Series. 6 cyl Parent Block Engine. Indirect Injection...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64472 | 108.0008 | 61.64834 | 28.99918 | 3.6868 | 4.252 | 2.4271 | 1.1417 |
1 cyl piston set 350185 for Bedford - 8.2 Litre 500 Engine Direct injection Diesel. CR 17 to 1, Al fin design RBP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
115.8875 | 122.428 | 75.7936 | 44.45 | 4 9/16 | 4.82 | 2.984 | 1 3/4 |
1 cyl piston set 350226 for Ford - 158 cubic inches, 32D Engine 3 cyl, Dexta Tractor, Series 6Y, 2000, Series 7A, 2600, 233. CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
106.69778 | 134.112 | 75.2983 | 38.1 | 4.2007 | 5.28 | 2.9645 | 1 1/2 |
4 cyl piston set 350269 for Leyland - 4 cyl 3.77 Litre Leyland 4/98 Series, 6 cyl 5.65 Litre 6/98, Normally Aspirated, Diesel, CR 16.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98 | 116.3 | 68.25 | 36.5125 | 3.858268 | 4.57874 | 2.687008 | 1 7/16 |
4 cyl piston set 350318 for Opel - 2068 cc 2.1D Engine, Blitz 2.1D, Rekord 2.1D, L, Berlina, Caravan, CR 21/22/24 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88 | 88.75 | 53.8 | 28 | 3.464567 | 3.494094 | 2.11811 | 1.102362 |
1 cyl piston set 350384 for Ford - 2496 cc 2.5DI Engine, Diesel Direct Injection Transit, CR 19 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.67012 | 94.00032 | 59.48426 | 29.00426 | 3.6878 | 3.7008 | 2.3419 | 1.1419 |
4 cyl piston set 350425 for Isuzu - 1817 cc 4FBI Engine Gemini 1800, Fargo WFR50
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84 | 74.75 | 44.8 | 25 | 3.307087 | 2.942913 | 1.76378 | 0.984252 |
4 cyl piston set 360001 for Fiat - 1116 cc OHC 128, 128 Sport Coupe 1100, L1100, 128 Special 1100, 128 3P 1100, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 72.3 | 35.3 | 22 | 3.149606 | 2.846457 | 1.389764 | 0.866142 |
1 cyl piston set 483506 for Lister - SR Series, Air Cooled Diesel
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9 | 103.1875 | 65.0875 | 29.36875 | 3 1/2 | 4 1/16 | 2 9/16 | 1 5/32 |
4 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
6 cyl piston set 664098 for Fiat - 2054 cc OHV 2100 Engine type 114, C.R 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 85.75 | 48.5 | 22 | 3.031496 | 3.375984 | 1.909449 | 0.866142 |
4 cyl piston set 665712 for Fiat - 1089 cc 1100/103, Engine type 103, CR 6.7 to 1. 1100R Engine Type 103H000, CR 8.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
4 cyl piston set 666074 for Seat - 1438 cc 1430, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 77.25 | 37.75 | 22 | 3.149606 | 3.041339 | 1.48622 | 0.866142 |
4 cyl piston set 667061 for Fiat - 4 cyl, 1049 cc 127AB.OC.O and 127AB.ON.O Engines, OHC. 127-1050 CL, 127 Fiorino, 147 Brazil, 60L Ritmo, CR 9.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 76.05 | 36.05 | 22 | 2.992126 | 2.994094 | 1.419291 | 0.866142 |
4 cyl piston set 667597 for Fiat - 1714 cc M700AA.17.0 Engine, 131 Mirafiori, 1600, 131, L, CL, Panorama, Regata Diesel, Ritmo Diesel, Strada/Ritmo Diesel. CR 20 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 85 | 45.9 | 22 | 3.267717 | 3.346457 | 1.807087 | 0.866142 |
4 cyl piston set 768120 for Simca - 1118 cc 1100G, 1100GLS, 350 Engine. CR 9.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
4 cyl piston set 036110 for Simca - 1290 cc OHV 1301S, 1301LS, 1301GL, CR 9 to 1, 1301GLS, CR 9.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 90.3 | 52 | 22 | 2.913386 | 3.555118 | 2.047244 | 0.866142 |
4 cyl piston set 129.14.07 for Peugeot - 2304 cc XD2-XD2P-XD94 Engines, 504 GLD/Berline/Familiale, 505 GRD/SRD, J7 PX/PY/PZ, J9, CR 22.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
94 | 99.9 | 57.42 | 28 | 3.700787 | 3.933071 | 2.26063 | 1.102362 |
4 cyl piston set 19116 JP for Vauxhall - 1972 On, 2279 cc OHC VX Four Ninety, Victor 2300SL, Magnum 2300. 1972/3 Viva 2300 SL, Firenza 2300 Sports SL, Low Comp CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
97.536 | 77.0636 | 39.0652 | 25.4 | 3.84 | 3.034 | 1.538 | 1 |
