Pistons
MG
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75.395 | 76.99375 | 42.06875 | 17.4625 | 2.968307 | 3 1/32 | 1 21/32 | 11/16 |
Morris
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Bedford M type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
6 cyl piston set 3339 for Vauxhall - 16.9h.p. 2048cc Cadet, VY
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 77.7875 | 41.275 | 22.225 | 2.65748 | 3 1/16 | 1 5/8 | 7/8 |
1 cyl piston set 4046 for Villiers - 148cc Longstroke, Two Port, X11C, GY, Two-Stroke with Deflector
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 53 | 91.28125 | 51.59375 | 12.5 | 2.086614 | 3 19/32 | 2 1/32 | 0.492126 |
6 cyl piston set 4823 for Essex - 16.9h.p. 2723cc Terraplane E78
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.46875 | 84.1375 | 46.0375 | 19.05 | 2 21/32 | 3 5/16 | 1 13/16 | 3/4 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
4 cyl piston set 5778 for Cadillac - V8 355E, 355D
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 118.665625 | 45.640625 | 22.225 | 3 3/8 | 4 43/64 | 1 51/64 | 7/8 |
4 cyl piston set 7450 for Mercedes - 13.4h.p. 1697cc 170V, 170H M28
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.5 | 79.5 | 38 | 11 | 2.893701 | 3.129921 | 1.496063 | 0.433071 |
6 cyl piston set 7672 for Austin - 13.9h.p. 1496cc Twelve Six, 12h/p/ 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.214 | 63.5 | 33.3375 | 14.2875 | 2.41 | 2 1/2 | 1 5/16 | 9/16 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
6 cyl piston set 7787 for Austin - 16h.p. Export
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 76.2 | 38.1 | 15.875 | 2.57874 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7807 for Standard - 10h.p. 1343cc C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 77.390625 | 39.290625 | 15.875 | 2 1/2 | 3 3/64 | 1 35/64 | 5/8 |
4 cyl piston set 7984 for Standard - 10h.p. 1267cc Flying Ten C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 19.05 | 2 1/2 | 2 7/8 | 1 1/2 | 3/4 |
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8499 for Armstrong Siddeley - 14h.p. 1668cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
6 cyl piston set 8735 for Lanchester - 14.06h.p. 1809 cc Fourteen, Roadrider De Luxe, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.468 | 80.16875 | 44.45 | 17.77 | 2.42 | 3 5/32 | 1 3/4 | 0.699606 |
4 cyl piston set 8825 for Ford - V8 30h.p. 3622cc SV 3.6 litre Pilot, C.R 6.15 to 1 British Built Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 8999 for Ford - 24h.p. A, AA, B, BB C.R. 4.6 to 1. Aluminium version of cast iron piston 8618
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 97.63125 | 48.41875 | 25.4 | 3 7/8 | 3 27/32 | 1 29/32 | 1 |
4 cyl piston set 9277 for Rover - 10h.p. 1185 cc Family 10
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 68.2625 | 33.3375 | 14.2875 | 2.480315 | 2 11/16 | 1 5/16 | 9/16 |
6 cyl piston set 9745 for Dodge - 27.3h.p. Aluminium version of cast iron piston 5297
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 97.63125 | 50.8 | 21.828125 | 3 3/8 | 3 27/32 | 2 | 55/64 |
1 cyl piston set 10154 for Bamford - EV3, EV4, EV5
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 90.884375 | 46.434375 | 25.4 | 4 1/4 | 3 37/64 | 1 53/64 | 1 |
4 cyl piston set 10491 for Vauxhall - 1939/48 12h.p. 1442 cc Twelve Four, I, CR 6.8 to 1. 1948/52 1 1/2 litre, Wyvern LIX, CR 6.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 90.884375 | 55.165625 | 15.875 | 2.73622 | 3 37/64 | 2 11/64 | 5/8 |
6 cyl piston set 11147 for Morris - 28.16h.p. 4459 cc OHV 4 1/2 Litre, CDD3 Saurer Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 126.20625 | 67.8688 | 34.925 | 3.425197 | 4 31/32 | 2.672 | 1 3/8 |
4 cyl piston set 11594 for Hillman - 1185 cc SV Minx, MkI, MkII, MkIII
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 73.81875 | 38.89375 | 16 | 2.480315 | 2 29/32 | 1 17/32 | 0.629921 |
4 cyl piston set 12380 for Standard - 803 cc OHV Eight, CR 7.25 to 1, Gold Star Power Plus, CR 8.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 66.1 | 38.1 | 15.875 | 2.283465 | 2.602362 | 1 1/2 | 5/8 |
4 cyl piston set 12574 for Austin - 15.99h.p. 2199cc OHV Sixteen from engine 1401 A70, Hampshire, Hereford, C.R 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 98.425 | 47.625 | 22.225 | 3 1/8 | 3 7/8 | 1 7/8 | 7/8 |
4 cyl piston set 12876 for Commer - 4cyl 13.95h.p. Q15/Q25. 6cyl 20.9h.p. N2/N3/N4/PN3/Q2/Q3, Superpoise, 30/40/60 Cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
6 cyl piston set 13337 for Austin - 28.8h.p. 3993 cc O.H.V. 4 Lit Princess MarkIV, CR 7.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
6 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 16312 for Fiat - 1089 cc OHV 1100/103TV, Three Ring Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
1 cyl piston set 17119 for Opel - Kadett S coupe, 1000S Engine, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 76 | 38 | 20 | 2.834646 | 2.992126 | 1.496063 | 0.787402 |
2 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
2 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
1 cyl piston set 17568 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 83.312 | 45.3136 | 25.4 | 3.374016 | 3.28 | 1.784 | 1 |
4 cyl piston set 17571 for Vauxhall - 1975 cc OHC Victor 2000 SL, Viva GT, VX Four Ninety, Firenza 2000 SL, Low Comp CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 81.0514 | 43.053 | 25.4 | 3 3/4 | 3.191 | 1.695 | 1 |
4 cyl piston set 18111 for Hillman - 875 cc OHC Imp, Super Imp, Husky C.R 10 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.98564 | 52.1843 | 26.797 | 15.875 | 2.6766 | 2.0545 | 1.055 | 5/8 |
2 cyl piston set 18320 for Yamaha - 248 cc YDS5, Two Port and Booster Ports, Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66.34 | 33.34 | 16 | 2.204724 | 2.611811 | 1.312598 | 0.629921 |
4 cyl piston set 18512 for Austin, Mini, Morris - OHV Mini Cooper Overbored to give 1095 cc, CR 10.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 51.384 | 31.547 | 15.875 | 2.57874 | 2.022992 | 1.242008 | 5/8 |
4 cyl piston set 18519 for Austin - 948cc OHV Healey Sprite MkI. CR 9.35 to 1/ MkII 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 18647 for Ford - Uprated 711M Engine, Ford Crossflow OHV Kent
1299 cc Original Application:
Ford Capri Mk1 1.3 08/1970-1974
Ford Capri Mk2/Mk3 1.3 1974-1987
Ford Cortina Mk3 1.3...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18680 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18697 for Triumph - 1296 cc OHV 1300, Herald 13/60, Toledo. CR 8.5 to 1. 1296 cc OHV 1300TC, Spitfire, CR 9 to 1 from Engine RD19477
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 66.9671 | 38.496875 | 20.6375 | 2.8995 | 2.6365 | 1 33/64 | 13/16 |
4 cyl piston set 18753 for Ford - 1593 cc OHC Cortina 1600 GT, Capri 1600/GT, Cortina 1600 L, Cortina 1600 XL, CR 9.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.65 | 73.1 | 41.2 | 24 | 3.450787 | 2.877953 | 1.622047 | 0.944882 |
4 cyl piston set 18944 for Ford - 1098 cc OHV Escort 1100, 2733E Engine, CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 83.82 | 44.1706 | 20.6375 | 3.187 | 3.3 | 1.739 | 13/16 |
4 cyl piston set 19113 for Bedford, Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC, CR 7.3/8.5 to 1. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 79.375 | 41.3766 | 25.4 | 3.374 | 3 1/8 | 1.629 | 1 |
4 cyl piston set 19160 for Leyland - 2227 cc OHC 2200 E series/2200HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 74.7776 | 43.1292 | 20.6375 | 3 8.8817841970013E-16/2 | 2.944 | 1.698 | 13/16 |
1 cyl piston set 19270 for Standard, Triumph - 1961/3 - Standard OHV 2 litre, Vanguard Six, E30/1, CR 8 to 1. 1964/9 - Triumph 2000, CR 8.5 to 1. 1965/70 2000 to Engine 50000, CR 9 to 1. 1967/70 -...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 74.1426 | 38.1508 | 20.6375 | 2.9405 | 2.919 | 1.502 | 13/16 |
1 cyl piston set 19298 for Ford - 7 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
6 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19470 for Hillman - 1295 cc OHV Avenger 1300, GL, GT, CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6 | 75.7682 | 44.1198 | 23.8125 | 3.094488 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19558 for Audi - 1470 cc Audi 80S/80LS/80GL, 1500s Engine. CR 9.7 to 1, steel strut design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.5 | 73.4 | 41.5 | 22 | 3.011811 | 2.889764 | 1.633858 | 0.866142 |
4 cyl piston set 19690 for Nissan - 1171 cc A12 Engine. Cherry 120a, Sunny 1200 120Y, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
4 cyl piston set 19727 for Opel - 1196 cc Kadett, L/Coupe/Caravan L, Rallye Kadett, Manta, Ascona, 1.2S, Kadette City, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 76 | 38 | 20 | 3.110236 | 2.992126 | 1.496063 | 0.787402 |
1 cyl piston set 19786 for Yamaha - 50 cc MF2, U5 Pal Scooterette, U5A Pal Scooterette, CR 7.4 to 1, V50, CR 6.6 to 1, V50P, V50M, FSIE Mo-Ped, FS1, FS1EDX, CR 7.1 to 1 , Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 50.2 | 25.3 | 12 | 1.968504 | 1.976378 | 0.996063 | 0.472441 |
4 cyl piston set 19913 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Popular 1300, Escort 8 cwt van, 751M Engine, Low Comp. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20008 for Datsun, Nissan - 1296 cc OHC Bluebird 1300, 510, (S, U, UT, D) U510 (SD) L13 Engine CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38 | 21 | 3.267717 | 3.070866 | 1.496063 | 0.826772 |
4 cyl piston set 20118 for Austin - 1695 cc Leyland 'O' series engine - Sherpa 200/230/250/255. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 72.04964 | 42.09796 | 20.6375 | 3.3245 | 2.8366 | 1.6574 | 13/16 |
4 cyl piston set 20183 for Mazda - 1586 cc NA Engine, OHC, Savanna, Capella, 616, 808, 818, B1600 Pick Up, CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 78.15 | 41.25 | 22 | 3.070866 | 3.076772 | 1.624016 | 0.866142 |
4 cyl piston set 20207 for Mazda - 1272 cc TC Engine Ohc 808, 818, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 70.35 | 38.45 | 20 | 2.874016 | 2.769685 | 1.51378 | 0.787402 |
1 cyl piston set 20264 for Range Rover - 3528 cc Rover V8, Range Rover SD1 Engine, CR 9.35 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.8619 | 77.089 | 47.371 | 22.225 | 3.4985 | 3.035 | 1.865 | 7/8 |
1 cyl piston set 20316 for Ford - 2.3 litre HF23 V6 Engine, OHV 20M, 2300S, 21M/TS 2300 S, 20M/RS, Cortina GL/S/Ghia, Taunus 2300 GXL/S/Sport/Coupe/Ghia, Capri 2300 GT/R, Capri II 2300 GT/S//Ghia,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 24 | 3.543307 | 0 | 0 | 0.944882 | ||
1 cyl piston set 20394 for MG, Mini - 1275 cc Austin OHV 1300, Princess 1300, Healey Sprite MkIV, 1300 MkV America, Allegro 1300. MG Midget MkIII, 1300 MkI. Mini 1275 GT, Cooper S. Morris 1300,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.625 | 69.723 | 38.0365 | 20.6375 | 2.780512 | 2.745 | 1.4975 | 13/16 |
4 cyl piston set 20414 for Datsun, Nissan - H20 Engine (4Cyl) 1982 cc OHV Cedric, Caball, Junior, Gloria, Clipper, Millar, Civilian (Bus) Caball Microbus, C4B, C5B Forklift Truck. Other...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.2 | 84 | 41 | 22 | 3.433071 | 3.307087 | 1.614173 | 0.866142 |
4 cyl piston set 20553 for Ford - 1599 cc OHV Transit 75/90/115, 751M Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20762 for Ford - 1117 cc CHV Engine, OHC, Escort, Escort L1100, GL, Ghia, High Comp CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 20.6375 | 2.913386 | 0 | 0 | 13/16 | ||
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
4 cyl piston set 21084 for Honda - 1602 cc EP Engine Accord 1600, Prelude 1600, Quintet, CR 8.4 to 1. 1751 cc EK Engine Accord 1800 CVCC, Prelude 1800 CVCC, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 62.5 | 27.6 | 18.006 | 3.031496 | 2.46063 | 1.086614 | 0.708898 |
4 cyl piston set 21181 for Nissan - 1488 cc E15 Engine, Pulsar 1500, Sunny 1500, Sentra USA Version, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 62.5 | 32.55 | 19 | 2.992126 | 2.46063 | 1.281496 | 0.748031 |
1 cyl piston set 21426 for Ford - 1993 cc Carb and Fuel Injection. Grenada 2.0i GL, Ghia, Ghia X, Sierra 2.0i S, GLS, Efi, Ghia, Capri 2000S, Granada 2000L, LX, GL, Sierra 2000 L, GL, LX, C, CL,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.8 | 69.55 | 41.6 | 24 | 3.574803 | 2.738189 | 1.637795 | 0.944882 |
4 cyl piston set 21855 for Nissan - 1595 cc Z16 Engine, OHC Cabstar 1 Tonne Pick-Up. OBF22 HU/LAU, BLF22 HT/LTE, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38 | 21 | 3.267717 | 3.070866 | 1.496063 | 0.826772 |
4 cyl piston set 24017 for Ford - 1297 cc (Courier, Escort 40/55/60/Popular, Fiesta) 1.3 Van, Fiesta Ghia/L/LA/LX. BL13CFI (HCS) Engine, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.96 | 54 | 29.35 | 18 | 2.911811 | 2.125984 | 1.155512 | 0.708661 |
1 cyl piston set 164518 for Leyland - 5.76 litre, 0350 Mk III, Comet 90, Comet 100, Tiger Cub, Diesel. Also suitable for Mk II
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.62718 | 132.715 | 81.915 | 33.02 | 3.9617 | 5.225 | 3.225 | 1.3 |
1 cyl piston set 350019 for Austin, Leyland - 2520 cc. OHV EA Series, 2 1/2 Lit. From Engines 25U/52B/D101 and 25V/597B/D101 Onwards. Diesel, CR 20.5 to 1. Al Fin Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 98.5266 | 57.2897 | 28.575 | 3 1/2 | 3.879 | 2.2555 | 1 1/8 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
1 cyl piston set 350122 for Ford - 3 cyl, Major 4000 Tractor, 201 cubic inches. 6 cyl, 8000, 8600 Tractor, 401 cubic inches. Diesel. CR 16.5 inches to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.76 | 127 | 68.1609 | 38.1 | 4.4 | 5 | 2.6835 | 1 1/2 |
1 cyl piston set 350199 for Ford - 3/4 cyl 175/256 cubic inches, Series 6Y, 3000, 5000, Super Major Tractor/Dexta, Series 7A, 3600, 333, 5600. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 129.0066 | 70.1802 | 38.1 | 4.2007 | 5.079 | 2.763 | 1 1/2 |
1 cyl piston set 350260 for Leyland - 6.54 litre Leyland 401 Engine, Serial No.1001 onwards, 411, 420 Engines, Turbocharged, Diesel CR 15.5 to 1 (Al Fin Design)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.2261 | 145.5928 | 82.1309 | 41.275 | 4.2215 | 5.732 | 3.2335 | 1 5/8 |
1 cyl piston set 350279 for Gardner - 6/8 Cyl, 6/8LXB Engine, CR 15 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 120.65 | 188.02858 | 111.85398 | 46.0375 | 4 3/4 | 7.4027 | 4.4037 | 1 13/16 |
1 cyl piston set 350364 for Ford - 4/6 cyl 4149/6224cc Dover 90/130 Engine, 255/380 cubic inch Cargo Ceries Trucks 0606/0709, 380cu.in Cargo Series Trucks 0713/0813/0913/1013, Truck/Tipper...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.188 | 119.888 | 71.247 | 36.5125 | 4.22 | 4.72 | 2.805 | 1 7/16 |
2 cyl piston set 350385 for Bedford - 8200 cc 500 phase 1 engine. Direct injection TM Series 7400000 -> Al fin design for 350262
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.8875 | 122.4788 | 75.82916 | 44.45 | 4 9/16 | 4.822 | 2.9854 | 1 3/4 |
4 cyl piston set 350500 for Rover - 1994 cc 86 bhp, 20 T2R (L Series) Engine, 220 D, 420 D/SD. CR 19.5 to 1, Turbo, Mechanical Direct Injection
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.5 | 76.95 | 48 | 30 | 3.326772 | 3.029528 | 1.889764 | 1.181102 |
1 cyl piston set 404112 for Lister - SL Series, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 103.1875 | 65.0875 | 26.9875 | 3 3/16 | 4 1/16 | 2 9/16 | 1 1/16 |
1 cyl piston set 554505 for Bedford - 6 cyl 7634 cc Direct Injection Diesel ERT/ERV/EPR/EMT/EMV/HMX/KMX, KG/KH/KM and YRT Series Trucks. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.824 | 122.4026 | 75.7936 | 38.1 | 4.56 | 4.819 | 2.984 | 1 1/2 |
1 cyl piston set 586006 for David Brown - 3 cyl 2395 cc 770, 4cyl 3195 cc 990, Direct Injection Diesel, CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 111.9124 | 66.7258 | 31.75 | 3.9388 | 4.406 | 2.627 | 1 1/4 |
4 cyl piston set 665384 for Fiat - 1481 cc OHV 1500, 1500C/L/TS, Engine Types 115, 115C. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 89 | 46 | 22 | 3.031496 | 3.503937 | 1.811024 | 0.866142 |
4 cyl piston set 665946 for Fiat - 1438 cc 124 Coupe 2nd Series, 124 Sport, 125 2nd Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 81.45 | 41.95 | 22 | 3.149606 | 3.206693 | 1.651575 | 0.866142 |
4 cyl piston set 666360 for Lancia - Beta 1600, CR 8.9 to 1, Beta Coupe 1600, Beta Spyder 1600, CR 9.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 81.75 | 42.25 | 22 | 3.149606 | 3.218504 | 1.663386 | 0.866142 |
4 cyl piston set 667509 for Alfa Romeo, Nissan - 1186 cc 301.00 Engine, Alfa Romeo Arna 1.2SI, Nissan Cherry 1.2, CR 9.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
4 cyl piston set 667894 for Alfa Romeo, Fiat, Fiat iveco, OM, Renault, Seat - 2446 cc 8140.61 Turbocharged Engine, Alfa Romeo 35 AR 8 Turbo Van. Fiat Ducato DS 2500. OM Grinta Van 30, 32, 35,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93 | 89.8 | 54.8 | 32 | 3.661417 | 3.535433 | 2.15748 | 1.259843 |
4 cyl piston set 10157JP for Austin - 10h.p. Ten Four, 1125cc. New manufacture by JP Pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
1 cyl piston set 18496 Talbot for Hillman - 1498 cc OHV Avenger Grand Luxe, GT CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.12124 | 75.803125 | 44.053125 | 23.8125 | 3.3906 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set M-0118202 for Opel - 2068 cc 44kW, CR 22 to 1, Rekord 2100D, Berlina D, Caravan D, Opel Blitz
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 94.75 | 53.75 | 28 | 3.464567 | 3.730315 | 2.116142 | 1.102362 |
