Pistons
4 cyl piston set 10007 for Austin - 15.99h.p. 2199cc OHV Sixteen to engine 1400 C.R 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 98.425 | 47.625 | 3 1/8 | 3 7/8 | 1 7/8 | ||
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 16224 for Austin - 1622cc OHV J2/J4, 10/18 Cwt. Omnivan/Omnitruck/Omnicoach. CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 2.9995 | 3 1/32 | 1 21/32 | ||
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
6 cyl piston set 3382 for Jaguar - 20h.p. 2663cc SSI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 79.375 | 39.6875 | 15.875 | 2 7/8 | 3 1/8 | 1 9/16 | 5/8 |
1 cyl piston set 4238 for Wolseley - 12.08h.p. 1271cc Hornet, High Comp. C.R 6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 70.64375 | 39.6875 | 14.2875 | 2.244094 | 2 25/32 | 1 9/16 | 9/16 |
6 cyl piston set 4830 for Humber - 16.95h.p. 2276cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 97.75 | 48 | 20 | 2.65748 | 3.848425 | 1.889764 | 0.787402 |
4 cyl piston set 5814 for Jowett - 10h.p. J, 7J, 8J, 9J, 10J, Flat Four C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 44.45 | 19.05 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 3/4 | 3/4 |
4 cyl piston set 7164 for Coventry Climax - 10h.p. 1122cc SV & OHV Type I, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.7875 | 36.5125 | 19.05 | 3 1/4 | 3 1/16 | 1 7/16 | 3/4 |
1 cyl piston set 7494 for Cletrac Tractor - BD Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 123.03125 | 76.99375 | 30.1625 | 3 3/4 | 4 27/32 | 3 1/32 | 1 3/16 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
6 cyl piston set 7672 for Austin - 13.9h.p. 1496cc Twelve Six, 12h/p/ 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.214 | 63.5 | 33.3375 | 14.2875 | 2.41 | 2 1/2 | 1 5/16 | 9/16 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
6 cyl piston set 7787 for Austin - 16h.p. Export
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 76.2 | 38.1 | 15.875 | 2.57874 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 7808 for Standard - 12h.p. 1608cc, C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.978125 | 39.290625 | 15.875 | 2.73622 | 3 7/64 | 1 35/64 | 5/8 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 7984 for Standard - 10h.p. 1267cc Flying Ten C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 19.05 | 2 1/2 | 2 7/8 | 1 1/2 | 3/4 |
1 cyl piston set 8057 for Morris - 8h.p. 918cc Eight, series E
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 63.5 | 28 | 15 | 2.244094 | 2 1/2 | 1.102362 | 0.590551 |
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 8499 for Armstrong Siddeley - 14h.p. 1668cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
4 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
6 cyl piston set 8735 for Lanchester - 14.06h.p. 1809 cc Fourteen, Roadrider De Luxe, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.468 | 80.16875 | 44.45 | 17.77 | 2.42 | 3 5/32 | 1 3/4 | 0.699606 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
6 cyl piston set 8829 for Morris - Oxford S II, 2062cc, 16h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 80.5 | 42.5 | 18 | 2.57874 | 3.169291 | 1.673228 | 0.708661 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
1 cyl piston set 9001 for Renault - 8.3h.p.SV, 1003 cc Juva RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 65.5 | 32.5 | 15 | 2.283465 | 2.57874 | 1.279528 | 0.590551 |
4 cyl piston set 9036 for Ford - V8 22h.p. 2227cc Utility, V8, 60h.p. Export, 74, 82A, 922A, 022A C.R.6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
6 cyl piston set 9301 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Cast Iron piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9327 for Vauxhall - 25h.p. 3215 cc from Engine No G8086
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.94 | 85.725 | 41.275 | 25.146 | 3.225984 | 3 3/8 | 1 5/8 | 0.99 |
1 cyl piston set 9748 for Douglas - 540cc SV Industrial Air Cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 84.1375 | 47.625 | 22.225 | 3 1/4 | 3 5/16 | 1 7/8 | 7/8 |
4 cyl piston set 10007 for Austin - 15.99h.p. 2199cc OHV Sixteen to engine 1400 C.R 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 98.425 | 47.625 | 22.225 | 3 1/8 | 3 7/8 | 1 7/8 | 7/8 |
4 cyl piston set 10157 for Austin - 10h.p. Ten Four, 1125cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
4 cyl piston set 10520 for Lanchester - 10h.p. 1203 cc Car 20051 Upwards, 1287 cc OHV Ten LD10, CR 7.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 17.77 | 2 1/2 | 2 7/8 | 1 1/2 | 0.699606 |
1 cyl piston set 10648 for Austin - 28.8 h.p. 3993 cc O.H.V. 4 litre Loadstar, 2-5 ton, 6 Cyl. Austin Champ 18.9HP, 2660 cc 4 Cyl.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
6 cyl piston set 11209 for Studebaker - 21.6h.p. 2708 cc SV Champion G
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 73.81875 | 40.48125 | 19.0373 | 3 8.8817841970013E-16/2 | 2 29/32 | 1 19/32 | 0.7495 |
4 cyl piston set 11479 for Commer - 16h.p. 2266 cc SV Q25, Super-poise, 25 cwt. Van
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.7339 | 93 | 51 | 24 | 3.1785 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11613 for Morris - 11.9h.p. 1550cc SV Twelve Four S11 1936 to 37, 11.9h.p. OHV Twelve Four, 'T' Series III 1938 to 41
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 80.5 | 42.5 | 18 | 2.73622 | 3.169291 | 1.673228 | 0.708661 |
4 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12380 for Standard - 803 cc OHV Eight, CR 7.25 to 1, Gold Star Power Plus, CR 8.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 66.1 | 38.1 | 15.875 | 2.283465 | 2.602362 | 1 1/2 | 5/8 |
4 cyl piston set 12503 for Ford - 8h.p. 933 cc SV 5 Cwt, H'lex
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 65.2526 | 31.115 | 17.4625 | 2.23 | 2.569 | 1.225 | 11/16 |
4 cyl piston set 12650 for Standard, Triumph - 948 cc OHV Ten, Pennant, 6 cwt Van, Atlas 10/12 Cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 66.1 | 38.1 | 15.875 | 2.480315 | 2.602362 | 1 1/2 | 5/8 |
4 cyl piston set 12877 for Commer - 13.95h.p. NI Series A, Q15, Q25, 15/20/25 Cwt. Early Models
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 13370 for Ford - 2353 cc SV F52A Vedette, V8, CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 68.2625 | 36.909375 | 17.4625 | 2.6 | 2 11/16 | 1 29/64 | 11/16 |
4 cyl piston set 14289 for Austin - 948 cc OHV A35/A40 Healey Sprite, High Comp CR 9.35 to 1. Healey Sprite MkII CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
6 cyl piston set 14816 for Austin - 2912 cc OHV A99 Westminster/A110 2.9 litre/ 3 litre Princess. CR 8.3 to 1 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
1 cyl piston set 15337 for AMC - 150 cc. 15H/15T, two stroke. 1Cyl Motorbike
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 55 | 81.2038 | 39.9288 | 14.27226 | 2.165354 | 3.197 | 1.572 | 0.5619 |
4 cyl piston set 16156 for Simca - 1290 cc OHV Aronde 1300, Flash Engine, 3 bearing crankshaft
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 86 | 48 | 22 | 2.913386 | 3.385827 | 1.889764 | 0.866142 |
4 cyl piston set 16224 for Austin - 1622cc OHV J2/J4, 10/18 Cwt. Omnivan/Omnitruck/Omnicoach. CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
1 cyl piston set 16844 for Vauxhall - 1964/6 1057 cc OHV Viva, CR 8.5 to 1 (7.5 when thick gasket fitted). 1966 OHV Viva 90, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.295 | 75.565 | 37.6174 | 20 | 2.925 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17482 for Datsun - 4 cyl 988 cc OHV 1000. CR 8 to 1. 1189 cc OHV Bluebird 1200, El Engine, 1299 cc OHV Bluebird 1300, P411, J Engine, CR 8.2 to 1. 6 cyl 1973 cc OHV Cedric De...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.5 | 17.4498 | 2.874016 | 2.65748 | 1.279528 | 0.687 |
2 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
6 cyl piston set 17731 for Austin - 2912 cc OHV 3 litre CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
1 cyl piston set 18393 for Jaguar - 3781 cc OHC Mk IX, 3.8 Lit, XK150 3.8, Mk X, S type, CR 8 TO 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.99 | 100.8634 | 52.5526 | 22.225 | 3.424803 | 3.971 | 2.069 | 7/8 |
4 cyl piston set 18522 for Ford - 1558 cc Twin OHC Lotus Cortina, Cortina Twin Cam, Escort Twin Cam CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 68.5673 | 39.4208 | 20.6375 | 3 1/4 | 2.6995 | 1.552 | 13/16 |
4 cyl piston set 18681 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18755 for Ford - 1993 cc OHC Cortina 2000, Cortina 2000L/XL/GXL/GT/E, Escort RS2000, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.8 | 79.55 | 41.65 | 24 | 3.574803 | 3.13189 | 1.639764 | 0.944882 |
4 cyl piston set 19113 for Bedford, Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC, CR 7.3/8.5 to 1. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 79.375 | 41.3766 | 25.4 | 3.374 | 3 1/8 | 1.629 | 1 |
6 cyl piston set 19270 for Standard, Triumph - 1961/3 - Standard OHV 2 litre, Vanguard Six, E30/1, CR 8 to 1. 1964/9 - Triumph 2000, CR 8.5 to 1. 1965/70 2000 to Engine 50000, CR 9 to 1. 1967/70 -...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 74.1426 | 38.1508 | 20.6375 | 2.9405 | 2.919 | 1.502 | 13/16 |
6 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19565 for Mercedes - 1965/8 1988 cc 200, 110B2, O309B, M121 Engine. 1969 Onwards 2197 cc 220 M115 Engine. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 88 | 48 | 26 | 3.425197 | 3.464567 | 1.889764 | 1.023622 |
4 cyl piston set 19734 for Chrysler (France)Simca - 1812 cc OHC 180, Europa 160 GT, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.7 | 87.1 | 49.06 | 24 | 3.452756 | 3.429134 | 1.931496 | 0.944882 |
4 cyl piston set 19913 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Popular 1300, Escort 8 cwt van, 751M Engine, Low Comp. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20126 for Ford - 957 cc, 1117 cc OHV Fiesta L/S, Ghia. CR 9.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.9394 | 65.1002 | 39.19982 | 20.6375 | 2.911 | 2.563 | 1.5433 | 13/16 |
4 cyl piston set 20207 for Mazda - 1272 cc TC Engine Ohc 808, 818, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 70.35 | 38.45 | 20 | 2.874016 | 2.769685 | 1.51378 | 0.787402 |
6 cyl piston set 20317 for Ford - 2551 cc 2.6 litre V6, 26M, 2600 S, RS2600, Capri 2600 RS/ GT, Granada L, GL, GXL, Ghia, S, GLS and Turnier, CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 74.78 | 40.38 | 24 | 3.543307 | 2.944094 | 1.589764 | 0.944882 |
4 cyl piston set 20414 for Datsun, Nissan - H20 Engine (4Cyl) 1982 cc OHV Cedric, Caball, Junior, Gloria, Clipper, Millar, Civilian (Bus) Caball Microbus, C4B, C5B Forklift Truck. Other...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.2 | 84 | 41 | 22 | 3.433071 | 3.307087 | 1.614173 | 0.866142 |
2 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
1 cyl piston set 21893 for Ford - 1597 cc CVH Engine Carburettor and Fuel Injection, Escort MkIII, MkIV XR3/XR3i, Fiesta XR2, Orion 1.6 GL, Ghia, Ghia i, Orion MkII 1.6 GL, Ghia, Ghia i, RS1600I...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.965 | 66.3 | 36.3 | 20.63496 | 3.148228 | 2.610236 | 1.429134 | 0.8124 |
6 cyl piston set 169405 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 121.7676 | 74.2696 | 36.5125 | 4 | 4.794 | 2.924 | 1 7/16 |
1 cyl piston set 350029 for Perkins - V8.510, NA180, From Engine 510U2000, 8.36 Litre, Direct Injection Diesel, CR 17.5 to 1 Al Fin Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 122.174 | 77.7875 | 41.275 | 4 1/4 | 4.81 | 3 1/16 | 1 5/8 |
1 cyl piston set 350142 for Leyland - 1798 cc OHV 185/215/220/240/250, Sherpa, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 89.916 | 50.2666 | 25.4 | 3.1595 | 3.54 | 1.979 | 1 |
1 cyl piston set 350199 for Ford - 3/4 cyl 175/256 cubic inches, Series 6Y, 3000, 5000, Super Major Tractor/Dexta, Series 7A, 3600, 333, 5600. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 129.0066 | 70.1802 | 38.1 | 4.2007 | 5.079 | 2.763 | 1 1/2 |
1 cyl piston set 350261 for Bedford - 8.2 litre 500 cubic inches engine, Phase 1, Direct Injection Diesel CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.8875 | 122.428 | 75.7936 | 44.45 | 4 9/16 | 4.82 | 2.984 | 1 3/4 |
1 cyl piston set 350300 for Ford - 3 Cyl 175 cubic inches, 1965 on Series 6Y, 3000 Super Dexta Tractor, 1975 on Series 7A, 3600, 333. 4 Cyl 256 cubic inches, 1965/8 series 6Y, 5000, Super Major...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.68 | 129.032 | 70.1802 | 38.1 | 4.2 | 5.08 | 2.763 | 1 1/2 |
4 cyl piston set 350374 for Opel - 1598 cc OHC Direct injecton Diesel, Ascona 1.6 Luxus D, Berlina D. Kadett Luxus D, Berlina D,CR 22.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 77 | 44.95 | 26 | 3.149606 | 3.031496 | 1.769685 | 1.023622 |
4 cyl piston set 350387 for Nissan - SD20 Engines, 1991 cc, Cedric, Homer, Junior Wagon, KRSE20, Laurel 200D, Q140, VRE20, CR 20 to 1, and SD22 Engines 2164 cc, Caball, Cabstar, Caravan, Cedric,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 96 | 48.057 | 26 | 3.267717 | 3.779528 | 1.892008 | 1.023622 |
4 cyl piston set 350500 for Rover - 1994 cc 86 bhp, 20 T2R (L Series) Engine, 220 D, 420 D/SD. CR 19.5 to 1, Turbo, Mechanical Direct Injection
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.5 | 76.95 | 48 | 30 | 3.326772 | 3.029528 | 1.889764 | 1.181102 |
1 cyl piston set 404112 for Lister - SL Series, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 103.1875 | 65.0875 | 26.9875 | 3 3/16 | 4 1/16 | 2 9/16 | 1 1/16 |
1 cyl piston set 554505 for Bedford - 6 cyl 7634 cc Direct Injection Diesel ERT/ERV/EPR/EMT/EMV/HMX/KMX, KG/KH/KM and YRT Series Trucks. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.824 | 122.4026 | 75.7936 | 38.1 | 4.56 | 4.819 | 2.984 | 1 1/2 |
4 cyl piston set 611120 for Simca - 1090 cc OHV 316 Etoile 6
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68 | 79 | 42.1 | 22 | 2.677165 | 3.110236 | 1.65748 | 0.866142 |
4 cyl piston set 665595 for Fiat - 903 cc 100 GL Engine, 127 Special, L/C/CL, 900T Pulmino, Fiorino, Panda 45. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 61.25 | 30.75 | 20 | 2.559055 | 2.411417 | 1.21063 | 0.787402 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
4 cyl piston set 667234 for Fiat - 1301 cc 131B.000 OHC, 131 Supermirafiori, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.05 | 82.95 | 38.45 | 22 | 2.994094 | 3.265748 | 1.51378 | 0.866142 |
4 cyl piston set 674110 for Simca - 1290 cc OHV Aronde, Rush Engine, CR 7.5 to 1. Rush Super engine CR 8.5 to 1. 1300, 1301 CR 8.3 to 1. 1301GL, 1301LS CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 78.5 | 42 | 22 | 2.913386 | 3.090551 | 1.653543 | 0.866142 |
4 cyl piston set 863120 for Simca - 1204 cc 1200S
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 64.2 | 37.5 | 22 | 2.913386 | 2.527559 | 1.476378 | 0.866142 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 129.44.37 for Peugeot - 2304 cc XD2 Engine, 504 GLD, 505 GRD, J7, J9, CR 22.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 99.9 | 57.42 | 30 | 3.700787 | 3.933071 | 2.26063 | 1.181102 |
