Pistons
MG
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75.395 | 76.99375 | 42.06875 | 17.4625 | 2.968307 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 7686 for Standard - 12h.p. 1608cc, Twelve, Flying Twelve
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.978125 | 39.290625 | 2.73622 | 3 7/64 | 1 35/64 | ||
TR4 (86mm std bore) +.060
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.98916 | 87.3125 | 50.8 | 22.225 | 3.3854 | 3 7/16 | 2 | 7/8 |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Bedford M
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 46.1264 | 20.6375 | 3 3/8 | 3 3/8 | 1.816 | 13/16 |
4 cyl piston set 16219 for Hillman - 1494 cc OHV Minx, 1 1/2 litre, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.99908 | 82.6008 | 47.0408 | 3.1102 | 3.252 | 1.852 | ||
4 cyl piston set 2727 for Thornycroft - 24.03h.p. TC4, Sturdy, Nippy, Beautyride, Tractor 3-5 ton. Heplex version of piston 5316
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 111.125 | 60.325 | 28.575 | 3 7/8 | 4 3/8 | 2 3/8 | 1 1/8 |
4 cyl piston set 3926 for Albion - 20/42h.p. LC43, LC44, LCA44, LE46, LEB46, LE47, LEA47, LEB47, M43, PH49, Victor BL118, 40/45/50cwt, 20 Passenger EN58
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 94.45625 | 42.06875 | 28.575 | 3 1/2 | 3 23/32 | 1 21/32 | 1 1/8 |
6 cyl piston set 4818 for Chrysler - CO 6 cyl, 33.8h.p. Heston, Kingston, CT-CZ, C1-C50, Saratoga, New Yorker, Newport. Cast Iron Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 93.6625 | 50.8 | 21.828125 | 3 1/4 | 3 11/16 | 2 | 55/64 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
6 cyl piston set 5674 for Standard - 20h.p. 2664cc Flying Twenty 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 78.978125 | 39.290625 | 19.05 | 2 7/8 | 3 7/64 | 1 35/64 | 3/4 |
4 cyl piston set 7085 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
6 cyl piston set 7397 for Commer - 22.6h.p. 30, 40, 60, 80cwt, N2, 3, 4, PN3, 20 seater Raider, Centaur, Centurian, Ambulance, Greyhound, Popular, B3, B30, B40, B50 Petrol
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 93 | 51 | 24 | 3.070866 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
6 cyl piston set 7670 for Austin - 16/6 2249cc Sixteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 76.2 | 44.45 | 14.2875 | 2.57874 | 3 8.8817841970013E-16/2 | 1 3/4 | 9/16 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
1 cyl piston set 7751 for Standard - 9h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7771 for Standard - 9.h.p 1052cc, Little 9, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.325 | 69.85 | 34.925 | 15.875 | 2 3/8 | 2 3/4 | 1 3/8 | 5/8 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 7807 for Standard - 10h.p. 1343cc C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 77.390625 | 39.290625 | 15.875 | 2 1/2 | 3 3/64 | 1 35/64 | 5/8 |
4 cyl piston set 7814 for Triumph - 13.95h.p. 1767cc Gloria Fourteen, Vitesse 14/60, Dolomite 14/60, Roadster 14/65
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 89.5 | 45 | 25.4 | 2.952756 | 3.523622 | 1.771654 | 1 |
6 cyl piston set 7903 for Austin - 12/6 12h.p. 10cwts
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.214 | 63.5 | 33.3375 | 14.2875 | 2.41 | 2 1/2 | 1 5/16 | 9/16 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8237 for Austin - 16h.p. Engine fitted to 12-6 chassis 1934-38, 16h.p. 1711cc Fourteen, Goodwood 1937-40, C.R 6.4 to 1, Tornado Marine Engine Model. 6 Cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 72.23125 | 33.3375 | 14.2875 | 2.57874 | 2 27/32 | 1 5/16 | 9/16 |
1 cyl piston set 8481 for Caterpillar - 2 Cylinder petrol starting engine for Diesel RD6, RD7, RD8 power units, D6100, D6600, D7700, D8800, D11000, D13000
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 107.95 | 61.9125 | 27.78125 | 3 5/8 | 4 1/4 | 2 7/16 | 1 3/32 |
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
4 cyl piston set 8713 for Morris - 25h.p. Overseas C.R 5.75 to 1, Aluminium, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 102.5 | 58 | 22 | 3.228346 | 4.035433 | 2.283465 | 0.866142 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
4 cyl piston set 8823 for Austin - 10.98h.p, 1237cc MPU Utility, C.R 6.52 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.548 | 69.85 | 31.75 | 14.2875 | 2.62 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 8892 for Fiat - 10.48h.p. 995cc 508 Balilla 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 82 | 42 | 18 | 2.559055 | 3.228346 | 1.653543 | 0.708661 |
4 cyl piston set 8999 for Ford - 24h.p. A, AA, B, BB C.R. 4.6 to 1. Aluminium version of cast iron piston 8618
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 97.63125 | 48.41875 | 25.4 | 3 7/8 | 3 27/32 | 1 29/32 | 1 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 9211 for Continental - F4162 Industrial F162, LF162, Power Unit PF162, Kerosene
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 21.828125 | 3 7/16 | 3 9/16 | 2 | 55/64 |
6 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9745 for Dodge - 27.3h.p. Aluminium version of cast iron piston 5297
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 97.63125 | 50.8 | 21.828125 | 3 3/8 | 3 27/32 | 2 | 55/64 |
1 cyl piston set 9964 for Thornycroft - 30.46h.p. 4.042 litre, Sturdy, YF/TR6, Indirect injection Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4875 | 111.125 | 60.325 | 31.75 | 3 9/16 | 4 3/8 | 2 3/8 | 1 1/4 |
6 cyl piston set 10083 for Chrysler - 28.35h.p. 4100cc, SV, C34, C38, C45, C48, C51, Royal, Windsor, Newport, 5 tonner, US Army
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 98.425 | 50.8 | 21.828125 | 3 7/16 | 3 7/8 | 2 | 55/64 |
6 cyl piston set 10171 for Bedford - 27.34h.p. 3519cc, series K, M, O, W, 3/4 to 5 Ton, Tractor 6 to 8 Ton, Heplex Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
4 cyl piston set 10491 for Vauxhall - 1939/48 12h.p. 1442 cc Twelve Four, I, CR 6.8 to 1. 1948/52 1 1/2 litre, Wyvern LIX, CR 6.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 90.884375 | 55.165625 | 15.875 | 2.73622 | 3 37/64 | 2 11/64 | 5/8 |
6 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11121 for Reliant - 747 cc Regent, Prince Regent, regal, 5-12 Cwt Three Wheeler Van. 598 cc Ohv Regal 3/25, 5 Cwt van, CR 7.8 to 1. Up to Engine 88757
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 55.88 | 46.0375 | 22.225 | 12.7 | 2.2 | 1 13/16 | 7/8 | 1/2 |
8 cyl piston set 11376 for Ford - 21.6h.p. 2158 cc SV Vedette, Comete, V8, 2.2 Litre
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
4 cyl piston set 11594 for Hillman - 1185 cc SV Minx, MkI, MkII, MkIII
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 73.81875 | 38.89375 | 16 | 2.480315 | 2 29/32 | 1 17/32 | 0.629921 |
6 cyl piston set 11809 for Humber - 29.4 h.p. 4139 cc OHV Super Snipe, Mk IV, Pullman, Imperial
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 112.9538 | 66.675 | 28.575 | 3 1/2 | 4.447 | 2 5/8 | 1 1/8 |
4 cyl piston set 12332 for Standard, Triumph - 2088 cc OHV 2.1 litre, 20S, Vanguard Four, Triumph 2.1 litre Roadster, 1800, 2000, Renown.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 87.4268 | 50.9016 | 22.225 | 3.346457 | 3.442 | 2.004 | 7/8 |
4 cyl piston set 12572 for Austin - 18.9h.p. 2660 cc O.H.V. Atlantic A90/Healey Hundred, 2.7 Lit. CR 7.5 to 1-4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
4 cyl piston set 13598 for Austin - 1489 cc OHV A50 Cambridge, High Comp CR 8.2 to 1. A50/A55 CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 14814 for Austin - 2912cc OHV Healey 3000 2.9 Litre. CR 9.03 to 1. 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
1 cyl piston set 16094 for Ford - 1340 cc OHV Classic 315, Capri 335, 109E Engine, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 77.1398 | 38.89375 | 20.6375 | 3.187 | 3.037 | 1 17/32 | 13/16 |
4 cyl piston set 16219 for Hillman - 1494 cc OHV Minx, 1 1/2 litre, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.99908 | 82.6008 | 47.0408 | 22.225 | 3.1102 | 3.252 | 1.852 | 7/8 |
1 cyl piston set 16558 for Honda - 86.7 cc OHV 90, C200, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 49 | 54 | 25.75 | 14 | 1.929134 | 2.125984 | 1.01378 | 0.551181 |
4 cyl piston set 17272 for Austin - 1275 cc OHV Marina 7-10 cwt. Van, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 69.6849 | 38.0365 | 20.6375 | 2.78 | 2.7435 | 1.4975 | 13/16 |
4 cyl piston set 17412 for Opel - 1078 cc Kadett, L/Coupe/Caravan L, Rallye Kadett LS, 1100SR, Olympia Coupe, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 76 | 38 | 20 | 2.952756 | 2.992126 | 1.496063 | 0.787402 |
4 cyl piston set 17566 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18508 for Ford - 1599 cc OHV Cortina 1600, Cortina 1600 GT, 2737E Engine High Comp, CR 10.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 83.82 | 44.1706 | 20.6375 | 3.187 | 3.3 | 1.739 | 13/16 |
1 cyl piston set 18647 for Ford - Uprated 711M Engine, Ford Crossflow OHV Kent
1299 cc Original Application:
Ford Capri Mk1 1.3 08/1970-1974
Ford Capri Mk2/Mk3 1.3 1974-1987
Ford Cortina Mk3 1.3...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18685 for Ford - 1599 cc OHV Cortina 1600, Capri 1600, 2737E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18942 for Vauxhall - 1256 cc OHV Viva De Luxe, Firenza De Luxe SL, Low Comp CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.95 | 68.6308 | 36.7284 | 20 | 3.187008 | 2.702 | 1.446 | 0.787402 |
6 cyl piston set 19160 for Leyland - 2227 cc OHC 2200 E series/2200HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 74.7776 | 43.1292 | 20.6375 | 3 8.8817841970013E-16/2 | 2.944 | 1.698 | 13/16 |
2 cyl piston set 19298 for Ford - 6 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 19470 for Hillman - 1295 cc OHV Avenger 1300, GL, GT, CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6 | 75.7682 | 44.1198 | 23.8125 | 3.094488 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19659 for Nissan - 988 cc A10 Engine. 79-81; Cherry 1.0 L, GL. 70-76; Cherry 100A Deluxe L. 76-79; Chery F11, GLS. 66-70; Sunny 1000
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
4 cyl piston set 19753 for Leyland - 1798 cc OHV 240, 250, Sherpa, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 61.1124 | 42.164 | 20.6375 | 3.1595 | 2.406 | 1.66 | 13/16 |
1 cyl piston set 19975 for Land Rover - OHV Series II, IIA, III, 2 1/4 Litre, CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20161 for Datsun - 1483 cc OHV J15 Engine, Pick Up Ng20, UN620, GN620, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.79 | 79.25 | 39.85 | 21 | 3.062598 | 3.120079 | 1.568898 | 0.826772 |
4 cyl piston set 20240 for Toyota - 2189 cc 20R Engine, Corona, Celica, CR 8.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.5 | 88.7 | 41.8 | 22 | 3.484252 | 3.492126 | 1.645669 | 0.866142 |
1 cyl piston set 20377 for Yamaha - 247 cc 1971 on, RD250 Reed Valve Engine, CR 7 to 1, 1976 on, RD250S, Type 1A2, Type 1A2, 1N9, RD250(s), Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 54 | 70 | 33.1 | 16 | 2.125984 | 2.755906 | 1.30315 | 0.629921 |
4 cyl piston set 20552 for Ford - 1599 cc OHV Escort 1600, Sport 1600, Ghia 1600, 751M Engine, High Comp CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20761 for Ford - 1296 cc CVH Engine OHC Escort 1300 L/GL, Ghia, Estate, CR 9.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.99984 | 20.6375 | 3.1496 | 0 | 0 | 13/16 | ||
4 cyl piston set 21072 for Nissan - 3956 cc P/P40/PF Engines, Cabstar Bus, Carrier Truck, Patrol 4WD, Carrier Bus. CR 7.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 94.5 | 53.35 | 20.653 | 3.374016 | 3.720472 | 2.100394 | 0.81311 |
4 cyl piston set 21077 for Austin, Morris - 1993 cc Princess 2000HL/HLS, Morris OHC Ital 2000 HLS Saloon/Estate, Ambassador 2.0 HL/HLS, Montego 2.0 HL/HLS, 'O' Series Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 60.2488 | 35.30092 | 20.6375 | 3.3245 | 2.372 | 1.3898 | 13/16 |
1 cyl piston set 21250 for Austin, Morris - 1275 cc A+ series, Maestro 1.3/L/HL/HLE, Metro L/HL/HLE/HLS/S, Montego 1.3, CR 9.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.6247 | 57.98566 | 38.0492 | 20.6375 | 2.7805 | 2.2829 | 1.498 | 13/16 |
1 cyl piston set 21426 for Ford - 1993 cc Carb and Fuel Injection. Grenada 2.0i GL, Ghia, Ghia X, Sierra 2.0i S, GLS, Efi, Ghia, Capri 2000S, Granada 2000L, LX, GL, Sierra 2000 L, GL, LX, C, CL,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.8 | 69.55 | 41.6 | 24 | 3.574803 | 2.738189 | 1.637795 | 0.944882 |
4 cyl piston set 22010 for Ford - 1294 cc CVH Engine OHC Leanburn, Escort 1400L/S/Ghia, Escort Combi, L/Ghia, Fiesta 1400L/S/Ghia, Orion 1400L/S/Ghia, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.24 | 76 | 38.69 | 20.61972 | 3.040945 | 2.992126 | 1.523228 | 0.8118 |
1 cyl piston set 181710 for David Brown - 3045 cc 990 Series Diesel, CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 99.21875 | 60.325 | 31.75 | 3 5/8 | 3 29/32 | 2 3/8 | 1 1/4 |
1 cyl piston set 249203 for Petter - PH Series, Diesel, CR 16.5 to 1. 3 7/16" bore for water cooled, 3.4435" for air cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 106 | 63.5 | 30 | 3 7/16 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 350051 for Ford - 4 cyl 2358 cc Transit 75/80/90/100/115/125/130/150/160/175/190, Vans 100, 150. York 2.4 litre. 3537 cc A Series. 6 cyl Parent Block Engine. Indirect Injection...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64472 | 108.0008 | 61.64834 | 28.99918 | 3.6868 | 4.252 | 2.4271 | 1.1417 |
1 cyl piston set 350083 for Bedford - 3614 cc 220 Engine D, K, T, TJ, TKV Series 1.1/4.4 Ton trucks, Diesel CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 103.124 | 118.237 | 71.501 | 34.925 | 4.06 | 4.655 | 2.815 | 1 3/8 |
1 cyl piston set 350225 for Ford - 6571 cc 401 Cu. In, 6 cyl Dexta Tractor, Series 7A, 9600, 9700, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 126.9746 | 67.8688 | 41.275 | 4.4007 | 4.999 | 2.672 | 1 5/8 |
1 cyl piston set 350254 for Petter - PH1, 1W, 2, 2W, 1/2 Cyls, Air cooled bore is 3.4435", Water is 3.4375"
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 105.9942 | 63.6016 | 30 | 3 7/16 | 4.173 | 2.504 | 1.181102 |
1 cyl piston set 350308 for MAN - 10343 cc D2156 Engine, MGN, MY, MNY, MYN, HNY HM2 HM3 HMN3 HMN5 HMN6 HM9 HMN9 HMUS; 9.192, 12.192, 15.192, 16.192,22.192, 16.186, 10.215, 12.215, 13.215, 16.215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 121 | 162 | 94 | 45 | 4.76378 | 6.377953 | 3.700787 | 1.771654 |
1 cyl piston set 350342 for Gardner - 6/8 Cyl, 6/8LXB Engine, CR 14 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 120.65 | 187.8584 | 111.70158 | 46.0375 | 4 3/4 | 7.396 | 4.3977 | 1 13/16 |
1 cyl piston set 350422 for Land Rover - 2494 cc 12J Engine, 90, 110, Defender 110, Defender 130. Diesel, CR 21 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.424 | 86.3092 | 54.5846 | 30.1498 | 3.56 | 3.398 | 2.149 | 1.187 |
1 cyl piston set 350494 for Volkswagen - 1588 cc, Caddy, all models, Golf, Industry Engine, Jetta, Passat (not 1982/6), Rabbit (USA), Santana, Transporter 245/247/251/253/255, CR 23 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.5 | 71.7 | 41.7 | 24 | 3.011811 | 2.822835 | 1.641732 | 0.944882 |
1 cyl piston set 483506 for Lister - SR Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 103.1875 | 65.0875 | 29.36875 | 3 1/2 | 4 1/16 | 2 9/16 | 1 5/32 |
4 cyl piston set 544009 for Lister - LR Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 103.1875 | 65.0875 | 25.4 | 3 8.8817841970013E-16/2 | 4 1/16 | 2 9/16 | 1 |
4 cyl piston set 663395 for Fiat - 633 cc OHV 600, Multipla RPB
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 70 | 40.8 | 18 | 2.362205 | 2.755906 | 1.606299 | 0.708661 |
4 cyl piston set 665256 for Fiat - 633 cc OHV 600, Multipla, Three Ring Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 70 | 40.8 | 18 | 2.362205 | 2.755906 | 1.606299 | 0.708661 |
4 cyl piston set 666351 for Fiat - 843 cc OHV Normal Engine 100G.000 CR 8.5 to 1. OHV 850 Super Eng 100G.002. 903 cc OHV 850 Coupe Engine 100GC.000, 850 Spyder Engine 100GS.000 CR 9.3 to 1, 850...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 66.45 | 35.95 | 20 | 2.559055 | 2.616142 | 1.415354 | 0.787402 |
4 cyl piston set 667234 for Fiat - 1301 cc 131B.000 OHC, 131 Supermirafiori, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.05 | 82.95 | 38.45 | 22 | 2.994094 | 3.265748 | 1.51378 | 0.866142 |
4 cyl piston set 667699 for Fiat - 1116 cc 138B.000 Engine, Ritmo 60L/CL, Strada 60 Comfort, Comfort CL, ES. Uno 55 Comfort, Super
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 75.15 | 35.5 | 22 | 3.149606 | 2.958661 | 1.397638 | 0.866142 |
1 cyl piston set 900033 for Ruston Hornsby - YB Series, Direct injection Diesel, RBP, Air and Water cooled available, 1/2 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 123.825 | 73.0758 | 34.925 | 3 1/2 | 4 7/8 | 2.877 | 1 3/8 |
1 cyl piston set 085907 for Lister - Freedom, FR Series Diesel RPB, (Chrome Rings must not be fitted in original bores, as they are chrome plated)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 127 | 73.0885 | 31.75 | 3 3/4 | 5 | 2.8775 | 1 1/4 |
4 cyl piston set 132.14.00 for Peugeot - 2498 cc XD3, XD3P Engines, 505 GRD/GLD/SRD, Break, Familiale, J9 Pick-Up, CR 23 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 96.42 | 53.92 | 30 | 3.700787 | 3.796063 | 2.122835 | 1.181102 |
6 cyl piston set KS-93.972.600 for BMW - Engine M30B35M.E7, 3450 cc, 735i
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92 | 72.85 | 39.85 | 22 | 3.622047 | 2.86811 | 1.568898 | 0.866142 |
