Pistons
Triumph
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
Austin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
4 cyl piston set 2326 for Ford - 14.9h.p. AF, ABF, C.R. 5.2 to 1, Aluminium version of 2481
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.597 | 89.69375 | 48.41875 | 25.4 | 3.055 | 3 17/32 | 1 29/32 | 1 |
4 cyl piston set 4607 for Scammell - 10h.p. 1292cc MH3, 3 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 67.865625 | 38.89375 | 15.875 | 2 1/2 | 2 43/64 | 1 17/32 | 5/8 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
6 cyl piston set 5422 for Morris - 21h.p. 2916cc Twenty One, OJ, Series II
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 51 | 95.5 | 22 | 2.952756 | 2.007874 | 3.759843 | 0.866142 |
4 cyl piston set 7085 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
6 cyl piston set 7371 for Gardner - 27.3h.p. M40, 046 2 to 5 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 103.98125 | 54.76875 | 22.225 | 3 3/8 | 4 3/32 | 2 5/32 | 7/8 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 7664 for Austin - 11.9h.p. 1535cc 12/4 C.R 6.2 to 1 4 cyl 1933-47, 17.9h.p. 2510cc fitted to 16h.p. chassis C.R 6.3 to 1, 6 cyl, Light 12/4, 8/10cwt 4cyl, 15cwt, Ambulance 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.342 | 79.375 | 38.1 | 15.875 | 2.73 | 3 1/8 | 1 1/2 | 5/8 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 7687 for Ford - 8h.p. Model Y, 5cwt, Tug, 40cwt, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 61.11875 | 26.19375 | 17.4625 | 2.23 | 2 13/32 | 1 1/32 | 11/16 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
4 cyl piston set 7765 for Morris - 10h.p. 1292cc Ten Four Series II, III
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
6 cyl piston set 7804 for Morris - 16h.p. 2062cc Oxford
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77 | 40.5 | 18 | 2.57874 | 3.031496 | 1.594488 | 0.708661 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 7819 for Rover - 10.8h.p. 21389cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 40.084375 | 78.184375 | 15.875 | 2.61811 | 1 37/64 | 3 5/64 | 5/8 |
4 cyl piston set 8041 for Triumph - 11.8h.p. 1496cc, 1.5 litre Dolomite
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69 | 85 | 45 | 19.05 | 2.716535 | 3.346457 | 1.771654 | 3/4 |
6 cyl piston set 8107 for Commer - 20/70h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 2.952756 | 0 | 0 | 0 | |||
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 8282 for Vauxhall - 14h.p. 1781cc, J, C.R 6.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 2.42126 | 0 | 0 | 0 | |||
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
1 cyl piston set 8684 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
4 cyl piston set 8788 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
6 cyl piston set 8967 for REO - IA4H, IA4HY, IB4 (After Eng 14000), H/M/Y, IB7M/MY, IC4H/HY, ID4, H/Y, IL5H, 2B, 4/4R/7M, 2D, 4/4M/4MH/4DR, 2H, R/5/5Z, 2J, R/5Z, 2K/2KR, 2L, M/4/4C/7M/7MF, DFX,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 101.996875 | 82.153125 | 25.003125 | 3 3/8 | 4 1/64 | 3 15/64 | 63/64 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 9178 for Lanchester - 10h.p. 1203 cc Car Nos 15000 to 20050
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.05625 | 38.1 | 15.875 | 2 1/2 | 2 23/32 | 1 1/2 | 5/8 |
1 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 9655 for John Deere - B, BI, BN, BW, BO, BR, Horizontal
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 114.3 | 142.875 | 82.55 | 31.242 | 4 1/2 | 5 5/8 | 3 1/4 | 1.23 |
4 cyl piston set 9984 for Singer - 9.93h.p. 1193cc Super 10, CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.246 | 68 | 33 | 14.2875 | 2.49 | 2.677165 | 1.299213 | 9/16 |
1 cyl piston set 10014 for Humber - 4 cyl 12h.p. 1669cc, 6 cyl 17.97h.p. 2731cc Snipe
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
4 cyl piston set 10345 for Perkins - PA, PB, P4, 4192, 14.7h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 3.501 | 0 | 0 | 0 | |||
1 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 10931 for Hillman - 1265 cc Minx Mark IV, V, VI, VII, SV, Husky, MkI, CR 6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.0875 | 73.92 | 39 | 17.4625 | 2 9/16 | 2.910236 | 1.535433 | 11/16 |
1 cyl piston set 11433 for International - Farmall M, MV, I6, IU6, O6, OS6, T6, W6, Power Unit U6, High Comp for 9591
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 146.05 | 90.4875 | 33.3375 | 3 7/8 | 5 3/4 | 3 9/16 | 1 5/16 |
4 cyl piston set 11582 for Morris - 10h.p. 1140 cc Series M, SM, Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
4 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12199 for Land Rover - 1997 cc 2 Litre, CR 6.73 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 93.4212 | 61.6712 | 17.4625 | 3.062992 | 3.678 | 2.428 | 11/16 |
4 cyl piston set 12503 for Ford - 8h.p. 933 cc SV 5 Cwt, H'lex
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 65.2526 | 31.115 | 17.4625 | 2.23 | 2.569 | 1.225 | 11/16 |
6 cyl piston set 12545 for Morris - 14h.p. 1818 cc Morris Series II and III, Fourteen Six, 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 70 | 42.5 | 18 | 2.42126 | 2.755906 | 1.673228 | 0.708661 |
4 cyl piston set 12650 for Standard, Triumph - 948 cc OHV Ten, Pennant, 6 cwt Van, Atlas 10/12 Cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 66.1 | 38.1 | 15.875 | 2.480315 | 2.602362 | 1 1/2 | 5/8 |
6 cyl piston set 12768 for Austin - 4 cyl 2660 cc OHV Champ, 5 cwt. 6 cyl 3993 cc OHV 4 Litre , Loadstar, 2-5 ton/ 4x4 1 ton, 6 cyl.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
6 cyl piston set 13337 for Austin - 28.8h.p. 3993 cc O.H.V. 4 Lit Princess MarkIV, CR 7.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 13557 for Austin - 9.8h.p. 948 cc OHV A35, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 14396 for Morris - 948 cc OHV Minor 1000, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
6 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 15755 for MG - 1622 cc OHV MGA1600 Mk II, Magnette Mk IV, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
1 cyl piston set 16216 for Austin - 1622 cc OHV A60, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16312 for Fiat - 1089 cc OHV 1100/103TV, Three Ring Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68 | 72 | 46 | 22 | 2.677165 | 2.834646 | 1.811024 | 0.866142 |
1 cyl piston set 16426 for Onan - AJ
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.85 | 66.675 | 30.1625 | 15.875 | 2 3/4 | 2 5/8 | 1 3/16 | 5/8 |
1 cyl piston set 17119 for Opel - Kadett S coupe, 1000S Engine, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 76 | 38 | 20 | 2.834646 | 2.992126 | 1.496063 | 0.787402 |
4 cyl piston set 17229 for Reliant - 598 cc OHV 3/25 from Enigine 88758
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 55.88 | 46.0375 | 22.225 | 14.2875 | 2.2 | 1 13/16 | 7/8 | 9/16 |
2 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 17363 for Audi - 1696 cc O.H.V. Audi 80/F103, 1700s-103 Engine. CR 11 to 1, SSD
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 72.5 | 43.5 | 24 | 3.149606 | 2.854331 | 1.712598 | 0.944882 |
2 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17560 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17571 for Vauxhall - 1975 cc OHC Victor 2000 SL, Viva GT, VX Four Ninety, Firenza 2000 SL, Low Comp CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 81.0514 | 43.053 | 25.4 | 3 3/4 | 3.191 | 1.695 | 1 |
1 cyl piston set 17916 for Triumph - 1964 1998 cc OHV 2000, CR 8.5 to 1. 1965/70 OHV 2000, CR 9 to 1. 1968 OHV 2000 PI, CR 9.5 to 1. 1967/1970 OHV Vitesse GT6, 2 Litre CR 9.5 to 1. 1968/70,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 74.1426 | 38.1 | 20.6375 | 2.9405 | 2.919 | 1 1/2 | 13/16 |
2 cyl piston set 18320 for Yamaha - 248 cc YDS5, Two Port and Booster Ports, Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66.34 | 33.34 | 16 | 2.204724 | 2.611811 | 1.312598 | 0.629921 |
4 cyl piston set 18495 for Hillman - 1248 cc OHV Avenger, De Luxe, Super, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6003 | 75.803125 | 44.053125 | 23.8125 | 3.0945 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18519 for Austin - 948cc OHV Healey Sprite MkI. CR 9.35 to 1/ MkII 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 18680 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18684 for Ford - 1599 cc OHV Cortina 1600, 1600GT, Capri 1600, 2737E Engine, CR 9 to 1. 1599 cc OHV Capri 1600GT CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18753 for Ford - 1593 cc OHC Cortina 1600 GT, Capri 1600/GT, Cortina 1600 L, Cortina 1600 XL, CR 9.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.65 | 73.1 | 41.2 | 24 | 3.450787 | 2.877953 | 1.622047 | 0.944882 |
4 cyl piston set 18802 for Austin - 1798 cc OHV 1800, 1800 HL, 1800 MkII/MkIII CR 9 to 1, 1800S MkII CR 9.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.23733 | 61.1124 | 42.164 | 20.6375 | 3.15895 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19113 for Bedford, Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC, CR 7.3/8.5 to 1. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 79.375 | 41.3766 | 25.4 | 3.374 | 3 1/8 | 1.629 | 1 |
2 cyl piston set 19131 for Ford - 1969-71 1996 cc OHV Capri 2000GT, V4, CR 8.9 to 1. 1972 onwards 2994 cc OHV Capri, Consul GT, Granada, Granada GXL, 3 litre V6, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 95.25 | 46.1391 | 23.8125 | 3.6869 | 3 3/4 | 1.8165 | 15/16 |
1 cyl piston set 19270 for Standard, Triumph - 1961/3 - Standard OHV 2 litre, Vanguard Six, E30/1, CR 8 to 1. 1964/9 - Triumph 2000, CR 8.5 to 1. 1965/70 2000 to Engine 50000, CR 9 to 1. 1967/70 -...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 74.1426 | 38.1508 | 20.6375 | 2.9405 | 2.919 | 1.502 | 13/16 |
4 cyl piston set 19298 for Ford - 5 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
6 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19558 for Audi - 1470 cc Audi 80S/80LS/80GL, 1500s Engine. CR 9.7 to 1, steel strut design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.5 | 73.4 | 41.5 | 22 | 3.011811 | 2.889764 | 1.633858 | 0.866142 |
4 cyl piston set 19658 for Datsun, Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
4 cyl piston set 19748 for Rover - 3528 cc OHV 3500, 3500S, V8, CR 9.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.8619 | 77.089 | 47.371 | 22.225 | 3.4985 | 3.035 | 1.865 | 7/8 |
2 cyl piston set 19938 for Honda - 249 cc OHC CB250, CB250K2, CB250K3, CB250K4, CB250G5, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 62.5 | 32.1 | 15 | 2.204724 | 2.46063 | 1.26378 | 0.590551 |
4 cyl piston set 20139 for Triumph - 1493 cc OHV 1500, CR 8.5 to 1. OHV 1500, 1500TC, Spitfire 1500, Dolomite 1500, 1500HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 58.0898 | 32.6898 | 20.6375 | 2.8995 | 2.287 | 1.287 | 13/16 |
4 cyl piston set 20228 for Datsun - 1288 cc B210 A13 Engine.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.452 | 2.874016 | 2.65748 | 1.283465 | 0.687087 |
1 cyl piston set 20351 for Yamaha - 398 cc RD400, RD400X
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64 | 72.2 | 40.3 | 16 | 2.519685 | 2.84252 | 1.586614 | 0.629921 |
4 cyl piston set 20548 for Ford - 1098 cc OHV Escort 6-8 cwt Van, Escorty 1100, Popular 1100, 751M Engine High Comp, CR 9 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20751 for Vauxhall - 1297 cc 1300 S Engine, OHC Astra 1300 L, GL. 1.3 S Engine OHC Nova 1.3 SR, CR 9.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 62.3 | 35.9 | 20 | 2.952756 | 2.452756 | 1.413386 | 0.787402 |
4 cyl piston set 21075 for Austin - 1695 cc 'O' Series OHC Ambassador 1.7L/HL, Princess 1700L/HL/HLS, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 73.37044 | 43.41876 | 20.64258 | 3.3245 | 2.8886 | 1.7094 | 0.8127 |
4 cyl piston set 23512 for Ford - 999 cc Fiesta Popular Plus L/LX/Ghia, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68.7 | 53.9 | 29.2 | 19 | 2.704724 | 2.122047 | 1.149606 | 0.748031 |
1 cyl piston set 234415 for Lister - HA, HB, HW Series, Diesel. CR 15.2 to 1. Water Cooled diameter is 4", Air Cooled is 4.002
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 127 | 73.0885 | 36.5125 | 4 | 5 | 2.8775 | 1 7/16 |
1 cyl piston set 350067 for Ford - 4D 240 cubic inches, D Series, 2701E Vertical, 2706E Inclined. 6D 360 cubic inches, D Series 2704E Vertical, 2709E Inclined. Diesel, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.11 | 71.0311 | 34.925 | 4 1/8 | 4.65 | 2.7965 | 1 3/8 |
6 cyl piston set 350227 for Ford - 6571 cc 401 Cu. In, 6 cyl Dexta Tractor, Series 6Y, 8000, Series 7A, 8600, 8700. CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 126.9746 | 68.1228 | 38.1 | 4.2007 | 4.999 | 2.682 | 1 1/2 |
4 cyl piston set 350318 for Opel - 2068 cc 2.1D Engine, Blitz 2.1D, Rekord 2.1D, L, Berlina, Caravan, CR 21/22/24 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 88.75 | 53.8 | 28 | 3.464567 | 3.494094 | 2.11811 | 1.102362 |
4 cyl piston set 350482 for Austin, Leyland, Perkins - 1994 cc Prima 65 Engine, Austin Maestro 2.0D, 500-700, City L Van, Maestro Clubman, DLX. Leyland Sherpa 200 Series, Crewbus Van. Perkins 4.20...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 77.09916 | 48.26 | 28 | 3.3245 | 3.0354 | 1.9 | 1.102362 |
4 cyl piston set 664162 for Fiat - 767 cc OHV 600D, Multipla
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62 | 62 | 31 | 20 | 2.440945 | 2.440945 | 1.220472 | 0.787402 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
2 cyl piston set 668051 for Fiat - 1585 cc, 131A1/AF1/B1 Engines, 1978/91; 131 1600, 131 Mirafiori L, LC, Panorama 1300, 131 Supermirafiori, Supermirafiori, 1976/81; 242/15 Van, 1974/8; 131...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84 | 77.95 | 38.45 | 22 | 3.307087 | 3.068898 | 1.51378 | 0.866142 |
1 cyl piston set 11592 JP for Ford - 4 cyl 15.63h.p. 1508 cc OHV Consul, 6cyl 23.44h.p. 2262 cc OHV Zephyr, Zodiac RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.4004 | 82.55 | 47.7012 | 20.6375 | 3.126 | 3 1/4 | 1.878 | 13/16 |
Singer
This set contains 3 x matched 4 ring pistons and 1 x 3 ring piston Old Stock
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 0 | 0 | 0 | 0 | ||||
