Pistons

Search in Pistons

Search by one or more dimension or specification (1 inch = 25.4mm)

Bore (mm)

Piston Height (mm)

Compression Height (mm)

Tolerance

±

Tolerance

±

Tolerance

±

Gudgeon Pin Dia. (mm)'

Tolerance

±

We supply Pistons for all makes of vintage and classic vehicle from AEC and Allis-Chalmers to Volkswagen and Volvo. To assist with part identification, we have compiled application data for a selection of the most popular makes and model of vehicle. Please search below by make, then model.

Make

Model & Year

If your make or mode of vehicle is not covered by our search facility, please email with details of your requirement (Make, Capacity, Bore Size, Model and Year) and we will provide links to the correct parts where available.

Piston Crown Type

Piston Crown Type

CEP P H 21418/STD-4 - Piston

From £222.20 (£266.64 inc. VAT @ 20%)

Ford

Comparable to other manufacturer part numbers - CEP P H 21418

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
81.3	64.55	41.6	20.63242	3.200787	2.541339	1.637795	0.8123

Year From:: 1984

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 21426/.5mm - Piston set

From £330.88 (£397.06 inc. VAT @ 20%)

Ford

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 21467/1mm - Piston set

From £276.87 (£332.24 inc. VAT @ 20%)

Audi 80 / 100 / VW

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 21484/STD-4 - Piston

From £222.20 (£266.64 inc. VAT @ 20%)

Ford

Comparable to other manufacturer part numbers - CEP P H 21484

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
80	73.25	36.5	19.983	3.149606	2.883858	1.437008	0.786732

Year From:: 1978
Year To:: 1989

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 21763/STD-1 - Piston

From £50.50 (£60.60 inc. VAT @ 20%)

Clayton

Comparable to other manufacturer part numbers - CEP P H 21763

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
85.0011	70	33.5	19.05	3.3465	2.755906	1.318898	3/4

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 21764/030 - Piston set

From £276.87 (£332.24 inc. VAT @ 20%)

Ford Sierra

Comparable to other manufacturer part numbers - 21764,

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 21774/015 - Piston Set

From £259.19 (£311.03 inc. VAT @ 20%)

Volvo.

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 21854/STD-4 - Piston

From £222.20 (£266.64 inc. VAT @ 20%)

Ford USA

Comparable to other manufacturer part numbers - CEP P H 21854

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
86	71	34	21.98	3.385827	2.795276	1.338583	0.865354

Year From:: 1982

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 21881/STD-4 - Piston

From £222.20 (£266.64 inc. VAT @ 20%)

Austin

Comparable to other manufacturer part numbers - 21083

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
76.2	64.89954	39.90086	20.6375	3 8.8817841970013E-16/2	2.5551	1.5709	13/16

Year From:: 1984

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 2235/STD-6 - Piston

From £1818.00 (£2181.60 inc. VAT @ 20%)

Leyland

Comparable to other manufacturer part numbers - CEP P H 2235

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
107.95	123	57	28.575	4 1/4	4.84252	2.244094	1 1/8

Year From:: 1929
Year To:: 1939

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 22463/010 - Piston set

From £232.75 (£279.30 inc. VAT @ 20%)

Mini 998cc 1988 - 1992
3 ring - flat top - press fit

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 22463/020-4 - Piston set

From £232.75 (£279.30 inc. VAT @ 20%)

Mini 998cc 1988 - 1992
3 ring - flat top - press fit

Comparable to other manufacturer part numbers - CEP P H 22463

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
64.516	53.7972	33.8582	15.875	2.54	2.118	1.333	5/8

Year From:: 1980
Year To:: 1992

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 22463/030-4 - Piston set

From £232.75 (£279.30 inc. VAT @ 20%)

Mini 998cc 1988 - 1992
3 ring - flat top - press fit

Comparable to other manufacturer part numbers - CEP P H 22463

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
64.516	53.7972	33.8582	15.875	2.54	2.118	1.333	5/8

Year From:: 1980
Year To:: 1992

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 22463/040-4 - Piston set

From £232.75 (£279.30 inc. VAT @ 20%)

Mini 998cc 1988 - 1992
3 ring - flat top - press fit

Comparable to other manufacturer part numbers - CEP P H 22463

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
64.516	53.7972	33.8582	15.875	2.54	2.118	1.333	5/8

Year From:: 1980
Year To:: 1992

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 22463/060-4 - Piston set

From £232.75 (£279.30 inc. VAT @ 20%)

Mini 998cc 1988 - 1992
3 ring - flat top - press fit

Comparable to other manufacturer part numbers - CEP P H 22463

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
64.516	53.7972	33.8582	15.875	2.54	2.118	1.333	5/8

Year From:: 1980
Year To:: 1992

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 230017/STD-4 - Piston

From £1212.00 (£1454.40 inc. VAT @ 20%)

Leyland

Comparable to other manufacturer part numbers - 230011

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
84.1756	98.2599	60.198	28.575	3.314	3.8685	2.37	1 1/8

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 234415/STD-1 - Piston

From £70.70 (£84.84 inc. VAT @ 20%)

Lister

Comparable to other manufacturer part numbers - CEP P H 234415

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
101.6	127	73.0885	36.5125	4	5	2.8775	1 7/16

Piston Crown Type:: Spec.

Wishlist Details & Ordering

Piston Crown Type

Piston Crown Type

CEP P H 238205/STD-1 - Piston

From £50.50 (£60.60 inc. VAT @ 20%)

International

Comparable to other manufacturer part numbers - CEP P H 238205

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
85.725	98.9838	50.9524	27.99842	3 3/8	3.897	2.006	1.1023

Wishlist Details & Ordering

Photograph for illustrative purposes only - not actual product shown

CEP P H 2398/STD-6 - Piston

From £1818.00 (£2181.60 inc. VAT @ 20%)

Leyland

Comparable to other manufacturer part numbers - CEP P H 2398

Metric (mm)				English (Inches)
Bore	Piston Height	Compression Height	Gudgeon Pin Dia.	Bore	Piston Height	Compression Height	Gudgeon Pin Dia.
115.8875	124.75	54	28.575	4 9/16	4.911417	2.125984	1 1/8

Piston Crown Type:: Dish
Year From:: 1927
Year To:: 1939

Wishlist Details & Ordering
